24/30496376 DC

This standard 24/30496376 DC BS EN 4266 Aerospace series - Bearing spherical plain, metal to metal, in corrosion resisting steel, cadmium plated - Wide series - Dimensions and loads - Inch series is classified in these ICS categories:

• 49.035 Components for aerospace construction

This document specifies the characteristics of spherical plain bearings, metal to metal, in corrosion resisting steel, cadmium plated and chromated, wide series, inch series for aerospace applications. They are intended for use in fixed or moving parts of the aircraft structure and their control mechanisms. They are used in the temperature range − 54 °C to 150 °C. As they are lubricated by means of the following greases: - Code A: Grease as per MIL-PRF-23827C, operating temperature range − 73 °C to 121 °C; - Code B: Grease as per MIL-PRF-81322G, operating temperature range − 54 °C to 177 °C. The range of application for bearings lubricated with grease per code A is limited to 121 °C. In both cases it is important to provide the spherical surface of the outer or inner ring with a dry-film lubricant as per MIL-PRF-46010G or equivalent (anti-seizing protection). The slide hole treatment either at the outer ring or inner ring.
