25/30500256 DC

This standard 25/30500256 DC BS EN 15594 Railway applications - Infrastructure - Restoration of rails by electric arc welding is classified in these ICS categories:

• 25.160.10 Welding processes
• 93.100 Construction of railways

This document specifies restoration by electric arc welding and is limited to the head of the rails only. This document describes the approval systems for consumables and procedures used in manual metal arc and flux cored metal deposit rail repair welding. This document includes the quality-related tasks and responsibilities of personnel involved in the electric arc repair welding of rails. This document applies to plain rail and switches and crossings manufactured from new Vignole railway rails R200, R220, R260, R260Mn, and R350HT grades rails of 27 kg/m and above as contained in EN 13674-1, EN 13674-2 and EN 13674-4. The permitted welding processes are limited to Electric Arc (EA) in accordance with EN ISO 4063 and are by description Process No 111: SMAW (Shielded Metal Arc Welding) and Process No 114: FCAW (Flux Cored Arc Welding). This document can be applied in situ, at line side or at out of track locations. The flash welded leg ends of austenitic manganese steel crossings are included in this document, except when located within 500 mm of manganese crossings. Where repairs are required within 500 mm, refer to EN 16725.
