BS 1098-1:1967

This standard BS 1098-1:1967 Specification for jig bushes is classified in these ICS categories:

• 21.060.60 Rings, bushes, sleeves, collars
• 25.060.20 Dividing and tool-workpiece holding devices

This British Standard relates to bushes to be fitted to jigs for the purpose of guiding twist drills or reamers. It is primarily dimensional, and the bushes standardized are intended for use with inch or metric drills and reamers as specified in BS 328-1¹⁾ and BS 122-2²⁾ respectively.

Provision is made for the following types of bushes:

1. Press fit bushes, which may be either headed or headless.
2. Renewable bushes, fixed type.
3. Renewable bushes, slip type.
4. Liners, which may be either headed or headless.

Dimensions and tolerances for headed and headless press fit bushes, fixed and slip type renewable bushes and headed and headless liner bushes for use with drills and reamers. Design, surface texture, hardness, concentricity of bore with outside diameter and roundness of bore.
