BS 1734:1951 Specification for micrometer heads

BS 1734:1951

Specification for micrometer heads

Format
Availability
Price and currency
English Secure PDF
Immediate download
162.14 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
16.21 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
48.64 EUR
English Hardcopy
In stock
162.14 EUR
Standard number:BS 1734:1951
Pages:10
Released:1951-04-16
ISBN:0 580 35798 8
Status:Standard
DESCRIPTION

BS 1734:1951


This standard BS 1734:1951 Specification for micrometer heads is classified in these ICS categories:
  • 17.040.30 Measuring instruments

This British Standard relates to micrometer heads having measuring ranges of:

  1. ½ in.
  2. 1 in.
  3. 13 mm.
  4. 25 mm.

It applies to micrometer heads with rotatable spindles and with non-rotatable spindles, classed according to the following ranges of thimble diameter (dia. D, Figure 1):—

Type 1 Below 1 in. thimble diameter.

Type 2 1 in. and below 2 in. thimble diameter.

Type 3 2 in. thimble diameter and over.

NOTE Micrometer heads of the larger types with non-rotatable spindles may be supplied to special orders with dimensions approximately similar to those given in Table 2 and to an accuracy similar to that shown in Table 4


Heads for assembly with measuring or machine tools. Three types, thimble diameters below 1 in, 1 in and below 2 in, 2 in and over; measuring ranges ½ in, 1 in, 13 mm, 25 mm. Material, micrometer screw, spindle, thimble and barrel adjustments, measuring faces and graduations, dimensions and standards of accuracy.
