immediate downloadReleased: 1980-09-30
BS 3641-2:1980
Symbols for machine tools Specification for numerical control symbols
Format
Availability
Price and currency
English Secure PDF
Immediate download
180.00 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
18.00 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
54.00 EUR
English Hardcopy
In stock
180.00 EUR
| Standard number: | BS 3641-2:1980 |
| Pages: | 22 |
| Released: | 1980-09-30 |
| ISBN: | 0 580 11558 5 |
| Status: | Standard |
DESCRIPTION
BS 3641-2:1980
This standard BS 3641-2:1980 Symbols for machine tools is classified in these ICS categories:
- 25.040.20 Numerically controlled machines
- 01.080.20 Graphical symbols for use on specific equipment
This British Standard specifies basic designs for symbols intended for use on indicator plates of numerically controlled (N.C.) machine tools.
Drawings in this standard indicate the form of symbols only, and not their absolute dimensions.
The standard gives recommendations for proportions to be used in the design of symbols, independent of actual dimensions, and provides for the grouping together of symbols selected according to individual requirements.
Examples of groupings of symbols are given in appendix A for guidance.
NOTE. An index to BS 3641 : Parts 1,2 and 3 is given in PD 6490.
Basic designs for symbols for use on indicator plates of numerically controlled machine tools.
