BS 4500:2009

This standard BS 4500:2009 Limits and fits. Guidance for system of cone (taper) fits and tolerances for cones from C = 1:3 to 1:500, lengths from 6 mm to 630 mm and diameters up to 500 mm is classified in these ICS categories:

• 17.040.10 Limits and fits

This British Standard gives guidance on a system of cone fits and tolerances for cones from C = 1:3 to 1:500 and lengths from 6 mm to 630 mm.

The appropriate tolerances of this British Standard can also be used for prismatic workpieces, for example wedges.

This British Standard applies to cones which are dimensioned and toleranced according to BS ISO 3040, Method 1, Basic Taper method. This means that the tolerances limit the variation of penetration of mating surfaces, each surface being within two limiting profiles of the same taper corresponding to the maximum material condition (MMC) and the least material condition (LMC).

This British Standard is derived from BS EN 20286, and is a complement to BS EN ISO 1119.

NOTE For dimensioning and tolerancing cones on drawings, see BS ISO 3040.
