immediate downloadReleased: 2004-04-22
BS 4999-103:2004 General requirements for rotating electrical machines Specification for symbols

BS 4999-103:2004

General requirements for rotating electrical machines Specification for symbols

Format
Availability
Price and currency
English Secure PDF
Immediate download
162.14 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
16.21 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
48.64 EUR
English Hardcopy
In stock
162.14 EUR
Standard number:BS 4999-103:2004
Pages:12
Released:2004-04-22
ISBN:0 580 43586 5
Status:Standard
DESCRIPTION

BS 4999-103:2004


This standard BS 4999-103:2004 General requirements for rotating electrical machines is classified in these ICS categories:
  • 29.160.30 Motors

This part of BS 4999 specifies symbols for identification of dimensions of frame sizes for rotating electrical machines which are outside the scope of BS EN 50347. It specifies symbols for dimensions of skirt-mounted motors, pad-mounted motors, slide rails, shaft ends and keyways, and shaft ends with one or with two tapped holes.

NOTE Information on the system of frame nomenclature applicable to the motors covered by this part of BS 4999 is given in Annex A.
