immediate downloadReleased: 1985-11-29
BS 4G 173-2:1985
Connectors for ground electrical supplies for aircraft Specification for dimensions
Format
Availability
Price and currency
English Secure PDF
Immediate download
162.14 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
16.21 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
48.64 EUR
English Hardcopy
In stock
162.14 EUR
| Standard number: | BS 4G 173-2:1985 |
| Pages: | 14 |
| Released: | 1985-11-29 |
| ISBN: | 0 580 14708 8 |
| Status: | Standard |
DESCRIPTION
BS 4G 173-2:1985
This standard BS 4G 173-2:1985 Connectors for ground electrical supplies for aircraft is classified in these ICS categories:
- 49.100 Ground service and maintenance equipment
This p art of ISO 4 61 specifies the dimensions for the following connectors used to supply electrical power from a ground source to an aircraft:
Style 1A – 28 V d.c., aircraft fixed connector
Style 1B – 28 V d.c., ground supply free connector
Style 2A – 112 V d.c., aircraft fixed connector
Style 2B – 112 V d.c., ground supply free connector
Style 3A – 200 V a.c., 400 Hz, 3-phase aircraft fixed connector
Style 3B – 200 V a.c., 400 Hz, 3-phase ground supply free connector
NOTE ISO 461-1 specifies the design, performance and test requirements for the connectors.
