BS 5078:1974

This standard BS 5078:1974 Specification for jig and fixture components is classified in these ICS categories:

• 25.060.20 Dividing and tool-workpiece holding devices

This British Standard specifies dimensions and materials and, where appropriate, tolerances for the following jig and fixture components:

base and jig plates

circular and rectangular blanks, bolsters, plates and blocks

clamps

clamp buttons, heel pins and jig feet

sections

nuts

spherical seatings and washers

knobs

“C” washers

shoulder screws.

A reference number has been allocated to each individual item to facilitate identification.

NOTE The titles of the British Standards referred to in this standard are listed on the inside back cover.

Specifies dimensions and materials and, where appropriate, tolerances for the following components: base and jig plates, circular and rectangular blanks, bolsters, plates and blocks, clamps, clamp buttons, heel pins and jig feet, sections, nuts, spherical seatings and washers, knobs, 'C' washers and shoulder screws.
