BS 5472:1977

This standard BS 5472:1977 Specification for low voltage switchgear and controlgear for industrial use. Terminal marking and distinctive number. General rules is classified in these ICS categories:

• 29.130.20 Low voltage switchgear and controlgear

This standard applies to switchgear and controlgear for industrial use having rated voltages not exceeding 1 000 V a.c. and 1 200 V d.c. It is based on the uniform system of terminal marking specified in IEC-Publication 445-1973¹⁾.

The use of this system is recommended for the terminal marking of devices which are frequently contained in low voltage switchgear and controlgear assemblies, when such marking is a requirement of the relevant equipment standard or is usual practice.

Where an identifying colour, in accordance with a recognized system, is applied to an apparatus terminal, the correlation between this colour and the equivalent graphical symbol or the alphanumerical notation according to this standard shall, where necessary, be recorded on an associated drawing or document.

This standard forms the general rules. Additional European standards will give the rules for particular types of devices such as contactor relays, contactor auxiliary contacts, control switches, etc.

The terminal marking applies to devices as delivered by the manufacturer.

Terminal marking specified in detail for switchgear and controlgear. The 'distinctive number' is a convention indicating the switching capacity. English language version of EN 50005, based on an established international system for devices generally.
