BS 5590:1978 Specification for screw thread metric series measuring cylinders

BS 5590:1978

Specification for screw thread metric series measuring cylinders

Format
Availability
Price and currency
English Secure PDF
Immediate download
162.14 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
16.21 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
48.64 EUR
English Hardcopy
In stock
162.14 EUR
Standard number:BS 5590:1978
Pages:14
Released:1978-05-31
ISBN:0 580 35087 8
Status:Standard
DESCRIPTION

BS 5590:1978


This standard BS 5590:1978 Specification for screw thread metric series measuring cylinders is classified in these ICS categories:
  • 21.040.10 Metric screw threads

This standard relates to measuring cylinders for standard pitches of ISO metric threads given in BS 3643. The cylinders described are intended for use on threads of small helix angle, i.e. less than 5°.

Cylinders for measuring the pitch diameter of Unified, Whitworth form and B. A. threads are specified in Appendix C . (See BS 84, BS 93 and BS 1580 for details of these threads.)


Relates to measuring cylinders for ISO metric threads given in BS 3643. Appendix covers cylinders for use with Unified, Whitworth form and BA threads.
