BS 6361:1988 Specification for three-pin plug connectors for electrically controlled fluid power equipment

BS 6361:1988

Specification for three-pin plug connectors for electrically controlled fluid power equipment

Format
Availability
Price and currency
English Secure PDF
Immediate download
151.20 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
15.12 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
45.36 EUR
English Hardcopy
In stock
151.20 EUR
Standard number:BS 6361:1988
Pages:12
Released:1988-08-31
ISBN:0 580 16635 X
Status:Standard
DESCRIPTION

BS 6361:1988


This standard BS 6361:1988 Specification for three-pin plug connectors for electrically controlled fluid power equipment is classified in these ICS categories:
  • 23.100.99 Other fluid power system components

This British Standard specifies the following characteristics and requirements for a general purpose three-pin electrical plug connector with earth contact for use with a single solenoid:

  • the electrical characteristics of the connector;
  • the dimensions of the pins and earth contact;
  • the means for fixing the socket to the plug;
  • the sealing procedure between the plug and the socket.

The electrical plug connector specified in this British Standard is intended to be used under working conditions where the connector cannot be damaged by external action (for example shock or excessive loading).


Characteristics and requirements for a general purpose electrical connector with earth contact for use with single solenoid operators for control valves and intended for use in conditions where they are protected from physical damage. Includes a national appendix making recommendations for safe wiring configurations for certain types of valve used in hydraulic systems.
