BS 6600-10:1985

This standard BS 6600-10:1985 Outline dimensions of transformers and inductors for use in telecommunication and electronic equipment is classified in these ICS categories:

• 29.180 Transformers. Reactors

This Part of BS 6600 specifies the overall and fixing centre dimensions of transformers and inductors, using the Q range of C-cores in accordance with BS 5347, for assembly forms C, H, J and U and also the screws to be supplied with them.

A preferred series of terminal positions together with their appropriate reference numbers is given in Appendix A for assembly forms C, H and J.

NOTE 1 Assembly forms C, H and J are well established and the reference letters used in earlier industrial and Ministry of Defence specifications (RCL 215 and RCL 216, DFF 5214 and DEF STAN 59-37) have been retained.

NOTE 2 The titles of the publications referred to in this standard are listed on the inside back cover.

Specifies the outline dimensions of transformers and inductors using the Q range of C-cores in accordance with BS 5347.
