immediate downloadReleased: 1975-01-15
BS 9133 N001 to 003:1975 Detail specification for single turn low power non-wirewound rotary potentiometers. Spindle insulated from resistance element, spindle and panel sealed or container, spindle and panel sealed. Full assessment level

BS 9133 N001 to 003:1975

Detail specification for single turn low power non-wirewound rotary potentiometers. Spindle insulated from resistance element, spindle and panel sealed or container, spindle and panel sealed. Full assessment level

Format
Availability
Price and currency
English Secure PDF
Immediate download
249.60 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
24.96 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
74.88 EUR
English Hardcopy
In stock
249.60 EUR
Standard number:BS 9133 N001 to 003:1975
Pages:24
Released:1975-01-15
ISBN:0 580 08108 7
Status:Standard
DESCRIPTION

BS 9133 N001 to 003:1975


This standard BS 9133 N001 to 003:1975 Detail specification for single turn low power non-wirewound rotary potentiometers. Spindle insulated from resistance element, spindle and panel sealed or container, spindle and panel sealed. Full assessment level is classified in these ICS categories:
  • 31.040.20 Potentiometers, variable resistors

Preferred resistance values 1.0, 2.2 and 4.7 in each decade; resistance laws - linear, non-linear and reverse non-linear; selection tolerances ±20%, ±10%; rated dissipation - spindle and panel sealed types 0.25 W and 1.375 W (linear law) - container, spindle and panel sealed 0.7 W (linear law) (rated dissipation halved for logarithmic and reverse logarithmic laws); temperature characteristic of resistance ±6.5%. Range of spindle and mounting details in appendices.
