BS 919-4:2007 Screw gauge limits and tolerances Limits of size for gauges for screw threads of unified form diameters 1/4 in and larger

BS 919-4:2007

Screw gauge limits and tolerances Limits of size for gauges for screw threads of unified form diameters 1/4 in and larger

Format
Availability
Price and currency
English Secure PDF
Immediate download
348.00 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
34.80 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
104.40 EUR
English Hardcopy
In stock
348.00 EUR
Standard number:BS 919-4:2007
Pages:70
Released:2009-09-30
ISBN:978 0 580 68659 7
Status:Standard
DESCRIPTION

BS 919-4:2007


This standard BS 919-4:2007 Screw gauge limits and tolerances is classified in these ICS categories:
  • 21.040.10 Metric screw threads

This British Standard specifies the limits of size for the following types of gauges, setting plugs and check plugs for the various classes of standard Unified Coarse (UNC), Unified Fine (UNF) and Unified Extra Fine (UNEF) threads specified in BS 1580-1.

  1. GO and NOT GO screw gauges:
    1. screw plug gauges;
    2. solid screw ring gauges;
    3. adjustable screw ring gauges;
    4. adjustable screw calliper gauges.
  2. Setting plugs for GO and NOT GO adjustable screw ring gauges and for GO and NOT GO adjustable screw calliper gauges:
    1. double length type;
    2. single length type.
  3. GO and NOT GO check plugs for solid screw ring gauges.
  4. GO and NOT GO plug gauges and GO and NOT GO calliper gauges for the crest diameters of product threads.

NOTE The values tabulated in this standard have been derived from the application of the tolerances specified in BS 919-1 to the limits of size given in 30207542_img1 BS 1580-1 30207542_img2, and reference should be made to the former standard for general information, details of the form of thread for Unified screw gauges, and tolerances on pitch and thread angle.
