BS EN 13181:2001

This standard BS EN 13181:2001 Ventilation for buildings. Terminals. Performance testing of louvres. Performance testing of louvres subject to simulated sand is classified in these ICS categories:

• 23.120 Ventilators. Fans. Air-conditioners
• 91.140.30 Ventilation and air-conditioning systems

This European Standard specifies a method for measuring the sand rejection efficiency of sand trap louvres subject to simulated sand and with inlet air flow through the louvre under test. The Standard considers a 1000 mm ´ 1000 mm section of sand trap louvre, or the nearest possible blade increment, for evaluation purposes. The purpose of the tests incorporated in this European Standard is as follows: a) Sand Rejection Effectiveness To establish the sand rejection effectiveness when subjected to various air flow rates through the assembly. b) Entry loss coefficient/Pressure requirements To establish the air pressure loss through the sand trap louvre at various air flow rates and by calculation Discharge Loss Coefficient.
