BS EN 14385:2004

This standard BS EN 14385:2004 Stationary source emissions. Determination of the total emission of As, Cd, Cr, Co, Cu, Mn, Ni, Pb, Sb, TI and V is classified in these ICS categories:

• 13.040.40 Stationary source emissions

This European Standard specifies a manual reference method for the determination of the mass concentration of specific elements in exhaust gases from hazardous and municipal waste incinerators [1]. The method is applicable to each of the specific elements in the concentration range of 0,005 mg/m³ to 0,5 mg/m³. Unless otherwise stated, concentrations are expressed at volumes under dry conditions, normalised to 273 K, 101,3 kPa, and oxygen content with a volume fraction of 11 %.

Specific elements according to this European standard are antimony (Sb), arsenic (As), cadmium (Cd), chromium (Cr), cobalt (Co), copper (Cu), lead (Pb), manganese (Mn), nickel (Ni), thallium (Tl), and vanadium (V).

This European Standard is also applicable for exhaust gases from other sources with a flue gas composition, similar to that given in Table 1. The performance characteristics of the method determined for waste incincerators cannot be extrapolated to be used for other types of matrix without any further validation work.

NOTE This European Standard has been validated with the described materials, equipment, sampling and digestion performances etc., followed by analyses with AAS and ICP. This does not exclude the use of other types that meet the requirements and proven to be equivalent to the described European Standard.

This European Standard has been validated for the determination of the mass concentration of metals in incineration exhaust gases, within the uncertainties stated in clause 9.

If mercury is to be determined as well, this may be sampled in a side stream arrangement of the sampling train (EN 13211).

Table 1 — Exhaust gas matrix

Parameter to be determined	Mass concentration range
total suspended matter	0 mg/m3	to	20 mg/m3
TOCa)	0 mg/m3	to	20 mg/m3
HCl	0 mg/m3	to	20 mg/m3
HF	0 mg/m3	to	2 mg/m3
SO2	0 mg/m3	to	100 mg/m3
CO	0 mg/m3	to	250 mg/m3
NOx as NO2	0 mg/m3	to	500 mg/m3
Volume fraction range
CO2	3 %	to	15 % (dry, actual)
H2O (ga)	10 %	to	35 % (actual)
O2	3 %	to	17 % (dry, actual)
Temperature	60 °C	to	200 °C

^a) total organic carbon
