BS EN 15316-4-2:2017

This standard BS EN 15316-4-2:2017 Energy performance of buildings. Method for calculation of system energy requirements and system efficiencies is classified in these ICS categories:

• 91.140.10 Central heating systems

This European Standard covers heat pumps for space heating, heat pump water heaters (HPWH) and heat pumps with combined space heating and domestic hot water production in alternate or simultaneous operation, where the same heat pump delivers the heat to cover the space heating and domestic hot water heat requirement.

The standard provides a calculation method under steady conditions that corresponds to one calculation step.

The results of this calculation are incorporated in larger building models and take in account the influence of the external conditions and building control that influence the energy requirements for heating supplied by the heat pump system.

The scope of this part is to standardize the:

• required inputs;

• calculation methods;

• required outputs

Generation for space heating and domestic hot water production of the following heat pump systems, including control of:

• electrically-driven vapour compression cycle (VCC) heat pumps;

• combustion engine-driven vapour compression cycle heat pumps;

• thermally-driven vapour absorption cycle (VAC) heat pumps,

using combinations of heat source and heat distribution listed in Table 1.

Table 1 — Heating sources and energy distribution

Source	Distribution
Outdoor air	Water
Exhaust-air
Indirect ground source with brine
Indirect ground source with water
Direct ground source (Direct expansion (DX)
Surface water
Ground water

This standard does not cover sizing or inspection of heat pumps.

This standard deals with heat generators for heating or for combined domestic hot water and heating service. Generators for domestic hot water only are taken into account into module M8-8.

NOTE 1 Heat pumps for cooling systems are taken into account into module M4–8.

NOTE 2 Heat pumps for space heating using air (distribution) are taken into account in module M5–8.

Other generation systems such as boilers are covered in other sub modules of part M3-8.

This is the revision of EN 15316-4-2:2008. The revision covers the adaptation of the standard to hourly and monthly energy calculation.

Table 2 shows the relative position of this standard within the set of EPB standards in the context of the modular structure as set out in EN ISO 52000-1.

NOTE 3 In CEN ISO/TR 52000-2 the same table can be found, with, for each module, the numbers of the relevant EPB standards and accompanying technical reports that are published or in preparation.

NOTE 4 The modules represent EPB standards, although one EPB standard may cover more than one module and one module may be covered by more than one EPB standard, for instance a simplified and a detailed method respectively. See also Clause 2 and Tables A.1 and B.1.

Table 2 — Position of this standard, within the modular structure of the set of EPB standards

Overarching			Building (as such)		Technical Building Systems
	Descriptions			Descriptions		Descriptions	Heating	Cooling	Ventilation	Humidification	Dehumidification	Domestic Hot water	Lighting	Building automation and control	Electricity production
sub1		M1	sub1	M2	sub1		M3	M4	M5	M6	M7	M8	M9	M10	M11
1	General		1	General	1	General	15316–1					15316–1
2	Common terms and definitions; symbols, units and subscripts		2	Building Energy Needs	2	Needs						12831–3 ?
3	Applications		3	(Free) Indoor Conditions without Systems	3	Maximum Load and Power	12831–1					12831–3
4	Ways to Express Energy Performance		4	Ways to Express Energy Performance	4	Ways to Express Energy Performance	15316–1					15316–1
5	Building Functions and Building Boundaries		5	Heat Transfer by Transmission	5	Emission and control	15316–2	15316–2
6	Building Occupancy and Operating Conditions		6	Heat Transfer by Infiltration and Ventilation	6	Distribution and control	15316–3	15316–3				15316–3
7	Aggregation of Energy Services and Energy Carriers		7	Internal Heat Gains	7	Storage and control	15316–5					15316–5 15316–4-3
8	Building Partitioning		8	Solar Heat Gains	8	Generation
					8–1	Combustion boilers	15316–4-1					15316–4-1
					8–2	Heat pumps	15316–4-2					15316–4-2
					8–3	Thermal solar Photovoltaics	15316–4-3					15316–4-3			15316–4-3
					8–4	On-site cogeneration	15316–4-4					15316–4-4			15316–4-4
					8–5	District heating and cooling	15316–4-5	15316–4-5							15316–4-5
					8–6	Direct electrical heater	15316–4-6					15316–4-6
					8–7	Wind turbines									15316–4-7
					8–8	Radiant heating, stoves	15316–4-8
9	Calculated Energy Performance		9	Building Dynamics (thermal mass)	9	Load dispatching and operating conditions
10	Measured Energy Performance		10	Measured Energy Performance	10	Measured Energy Performance	15378–3					15378–3
11	Inspection		11	Inspection	11	Inspection	15378–1					15378–1
12	Ways to Express Indoor Comfort		12	–	12	BMS
13	External Environment Conditions
14	Economic Calculation	15459–1

NOTE The shaded modules are not applicable
