BS EN 3155-045:2019 Aerospace Series: Electrical Contacts

Welcome to the world of precision and reliability with the BS EN 3155-045:2019 Aerospace Series. This product standard is a testament to the high standards and meticulous engineering that define the aerospace industry. Designed specifically for electrical contacts used in connection elements, this standard ensures that every component meets the rigorous demands of aerospace applications.

Product Overview

The BS EN 3155-045:2019 standard is a comprehensive guide for electrical contacts, specifically female, type A, with double crimping, class T. This standard is essential for manufacturers and engineers who are involved in the design, production, and maintenance of aerospace electrical systems. It provides detailed specifications and guidelines to ensure that electrical contacts perform reliably under the extreme conditions typical of aerospace environments.

Key Features

• Standard Number: BS EN 3155-045:2019
• Pages: 16
• Release Date: December 19, 2019
• ISBN: 978 0 539 05039 4
• Status: Standard

Why Choose BS EN 3155-045:2019?

In the aerospace industry, precision and reliability are not just desired; they are mandatory. The BS EN 3155-045:2019 standard ensures that electrical contacts are manufactured to the highest quality, providing peace of mind that they will function correctly in critical applications. Here are some reasons why this standard is indispensable:

• Reliability: Ensures consistent performance of electrical contacts in demanding aerospace environments.
• Compliance: Meets international aerospace standards, facilitating global trade and cooperation.
• Quality Assurance: Provides a benchmark for quality, helping manufacturers maintain high production standards.
• Safety: Reduces the risk of electrical failures, enhancing the safety of aerospace operations.

Applications

The BS EN 3155-045:2019 standard is applicable to a wide range of aerospace applications, including:

• Aircraft electrical systems
• Spacecraft and satellite connections
• Military aviation equipment
• Commercial aviation systems

Technical Specifications

This standard provides detailed specifications for the design and testing of electrical contacts. It covers aspects such as:

• Material selection and properties
• Dimensional tolerances
• Crimping techniques and requirements
• Environmental testing procedures

Conclusion

The BS EN 3155-045:2019 Aerospace Series is an essential standard for anyone involved in the aerospace industry. It ensures that electrical contacts are designed and manufactured to meet the highest standards of quality and reliability. By adhering to this standard, manufacturers can guarantee that their products will perform effectively in the most challenging environments, providing safety and reliability for aerospace operations.

Invest in the BS EN 3155-045:2019 standard today and ensure that your aerospace electrical systems are built to last.

BS EN 3155-045:2019

This standard BS EN 3155-045:2019 Aerospace series. Electrical contacts used in elements of connection is classified in these ICS categories:

• 49.060 Aerospace electric equipment and systems

This document specifies the required characteristics, tests and tooling applicable to female electrical contacts 045, type A, double crimping, class T, used in elements of connection according to EN 3155-002.

It shall be used together with EN 3155-001.

The associated male contact is defined in EN 3155-044.

Double crimping contact has a barrel which is design to crimp conductor and jacket of cable in two locations, one on the conductor and the other on the jacket. This way protect the conductor from mechanical strengths.
