immediate downloadReleased: 2013-12-31
BS EN 3375-012:2013
Aerospace series. Cable, electrical, for digital data transmission Single braid. Star Quad 100 ohms. 260°C. Type KH. Product standard
Format
Availability
Price and currency
English Secure PDF
Immediate download
191.18 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
19.12 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
57.35 EUR
English Hardcopy
In stock
191.18 EUR
| Standard number: | BS EN 3375-012:2013 |
| Pages: | 18 |
| Released: | 2013-12-31 |
| ISBN: | 978 0 580 83449 3 |
| Status: | Standard |
DESCRIPTION
BS EN 3375-012:2013
This standard BS EN 3375-012:2013 Aerospace series. Cable, electrical, for digital data transmission is classified in these ICS categories:
- 49.090 On-board equipment and instruments
This European Standard specifies the dimensions, tolerances, required characteristics and the mass of an AWG 24 shielded quad cable, type KH, intended for high speed (100 Mbit/s) full duplex Ethernet networks.
Linked to this particular application, the operating temperatures of the cable are between – 65 °C and 260 °C.
This cable is laser markable, this marking satisfies the requirements of EN 3838.
The characteristics impedance must be (100 ± 15) Ω.
