BS EN 3545-006:2015 Aerospace Series Connectors

Introducing the BS EN 3545-006:2015, a pivotal standard in the aerospace industry, designed to ensure the highest quality and reliability of electrical connectors. This standard is part of the esteemed Aerospace series, focusing on connectors that are not only rectangular and electrical but also come with both sealed and non-sealed rear options. These connectors are housed in durable plastic, equipped with a robust locking device, and are engineered to operate efficiently across a wide temperature range from -55°C to 175°C.

Key Features

• Standard Number: BS EN 3545-006:2015
• Pages: 12
• Release Date: April 30, 2015
• ISBN: 978 0 580 87667 7
• Status: Standard

Product Overview

The BS EN 3545-006:2015 standard is a comprehensive guide that outlines the specifications for aerospace connectors. These connectors are crucial components in the aerospace industry, where reliability and performance are non-negotiable. The standard ensures that the connectors meet stringent requirements, making them suitable for use in various aerospace applications.

Design and Construction

The connectors covered by this standard are designed with a rectangular shape, which is a common form factor in aerospace applications due to its space-efficient design. The plastic housing provides a lightweight yet durable solution, ensuring that the connectors can withstand the rigors of aerospace environments. The inclusion of a locking device enhances the security of the connection, preventing accidental disconnections that could lead to system failures.

Sealed and Non-Sealed Options

One of the standout features of these connectors is the availability of both sealed and non-sealed rear options. The sealed connectors are ideal for environments where moisture and contaminants are a concern, providing an additional layer of protection. On the other hand, the non-sealed connectors offer a cost-effective solution for applications where such protection is not necessary.

Temperature Resilience

Operating in extreme temperatures is a common requirement in aerospace applications. The BS EN 3545-006:2015 connectors are designed to function optimally in temperatures ranging from -55°C to 175°C. This wide temperature range ensures that the connectors can be used in various aerospace environments, from the freezing conditions of high altitudes to the intense heat generated by aircraft systems.

Male Coding and Attachment

The connectors feature male coding and attachment, which simplifies the installation process and ensures a secure fit. This design consideration is crucial in aerospace applications, where ease of maintenance and reliability are paramount.

Mounting System

The system for mounting on fixed housing (receptacle) is another critical aspect of this standard. It ensures that the connectors can be securely attached to the aircraft's structure, providing a stable and reliable connection point. This feature is essential for maintaining the integrity of the electrical systems in aerospace applications.

Why Choose BS EN 3545-006:2015?

The BS EN 3545-006:2015 standard is an essential resource for anyone involved in the design, manufacture, or maintenance of aerospace electrical systems. By adhering to this standard, manufacturers can ensure that their connectors meet the highest quality and performance standards, providing peace of mind to both manufacturers and end-users.

Whether you are an aerospace engineer, a manufacturer of aerospace components, or a maintenance professional, the BS EN 3545-006:2015 standard is an invaluable tool that will help you achieve excellence in your work. Its comprehensive guidelines and specifications ensure that you have all the information you need to produce and maintain top-quality aerospace connectors.

Conclusion

In the demanding world of aerospace, where every component must perform flawlessly, the BS EN 3545-006:2015 standard stands as a testament to quality and reliability. By incorporating this standard into your processes, you are not only ensuring compliance but also enhancing the safety and efficiency of aerospace systems. Trust in the BS EN 3545-006:2015 to guide you in achieving the highest standards of excellence in aerospace electrical connectors.

BS EN 3545-006:2015

This standard BS EN 3545-006:2015 Aerospace series. Connectors, electrical, rectangular, with sealed and non-sealed rear, plastic housing, locking device, operating temperatures -55°C to 175°C is classified in these ICS categories:

• 49.060 Aerospace electric equipment and systems

This European Standard specifies the male coding and attachment system for mounting on fixed housing in the family of rectangular electrical connectors with sealed and non-sealed rear, plastic housing, locking device, for operating temperatures from –55 °C to 175 °C.
