BS EN 3645-003:2015 Aerospace Series Connectors

Welcome to the world of advanced aerospace technology with the BS EN 3645-003:2015 standard. This comprehensive product standard is a must-have for professionals in the aerospace industry, providing detailed specifications for electrical connectors that are circular, scoop-proof, and feature a triple start threaded coupling. Designed to operate at high temperatures, this standard ensures reliability and performance in demanding environments.

Key Features

• Standard Number: BS EN 3645-003:2015
• Pages: 14
• Release Date: February 28, 2015
• ISBN: 978 0 580 87966 1
• Status: Standard

Product Overview

The BS EN 3645-003:2015 standard is part of the prestigious Aerospace series, focusing on electrical connectors that are crucial for the safety and efficiency of aerospace operations. These connectors are designed with a circular shape and a scoop-proof feature, ensuring that they can withstand the rigors of aerospace applications. The triple start threaded coupling provides a secure and reliable connection, essential for maintaining the integrity of electrical systems in aircraft.

Temperature Resilience

One of the standout features of this standard is its specification for connectors that can operate continuously at temperatures of either 175 °C or 200 °C. This high-temperature resilience is critical for aerospace applications, where components are often exposed to extreme conditions. By adhering to this standard, manufacturers can ensure that their connectors will perform reliably even in the most challenging environments.

Receptacle Square Flange Mounting

The BS EN 3645-003:2015 standard also specifies the use of a receptacle square flange mounting. This design choice provides a robust and stable mounting solution, ensuring that the connectors remain securely in place during operation. The square flange design is particularly beneficial in aerospace applications, where vibration and movement can pose significant challenges.

Why Choose BS EN 3645-003:2015?

Choosing the BS EN 3645-003:2015 standard means opting for a product that has been meticulously designed to meet the highest standards of quality and performance. This standard is recognized internationally, making it a reliable choice for aerospace manufacturers and engineers around the globe. By implementing this standard, you can be confident that your electrical connectors will meet the rigorous demands of the aerospace industry.

International Recognition

The BS EN 3645-003:2015 standard is part of a series that is widely recognized and respected in the aerospace industry. This international recognition ensures that products designed to this standard will be accepted and trusted by aerospace professionals worldwide. Whether you are manufacturing components for commercial aircraft, military jets, or space exploration vehicles, this standard provides the assurance of quality and reliability.

Comprehensive Guidance

With 14 pages of detailed specifications, the BS EN 3645-003:2015 standard offers comprehensive guidance for the design and manufacture of aerospace connectors. This level of detail ensures that every aspect of the connector's performance is covered, from its physical dimensions to its electrical characteristics. By following this standard, manufacturers can produce connectors that meet the exacting requirements of the aerospace industry.

Conclusion

In the fast-paced and demanding world of aerospace technology, having the right standards in place is crucial for success. The BS EN 3645-003:2015 standard provides the detailed specifications needed to design and manufacture high-performance electrical connectors that can withstand the challenges of aerospace applications. With its focus on temperature resilience, secure mounting, and international recognition, this standard is an invaluable resource for aerospace professionals seeking to ensure the quality and reliability of their products.

Invest in the BS EN 3645-003:2015 standard today and take a step towards ensuring the success and safety of your aerospace projects.

BS EN 3645-003:2015

This standard BS EN 3645-003:2015 Aerospace series. Connectors, electrical, circular, scoop-proof, triple start threaded coupling, operating temperature 175 °C or 200 °C continuous is classified in these ICS categories:

• 49.060 Aerospace electric equipment and systems

This European Standard specifies the characteristics of square flange mounted receptacles in the family of circular electrical connectors with triple start threaded coupling.

It applies to models in Table 3.

For contacts, sealing plugs and cable outlet accessories associated with this receptacle see EN 3645‑002 . For plugs and protective covers, see EN 3645‑008 , EN 3645‑011 , EN 3645‑012 and EN 3645‑006 respectively.

These connectors are derived from and are interchangeable with those in standard MIL‑DTL‑38999/20 .
