BS EN 3645-008:2015 Aerospace Series Connectors

Introducing the BS EN 3645-008:2015, a pivotal standard in the aerospace industry, designed to ensure the highest level of performance and reliability for electrical connectors. This standard is essential for professionals seeking to implement cutting-edge technology in aerospace applications, where precision and durability are paramount.

Product Overview

The BS EN 3645-008:2015 standard specifies the requirements for electrical, circular, scoop-proof connectors with a triple start threaded coupling. These connectors are engineered to operate at continuous temperatures of 175 °C or 200 °C, making them ideal for high-temperature environments commonly found in aerospace applications.

Key Features

• Triple Start Threaded Coupling: Ensures a secure and reliable connection, minimizing the risk of disconnection under vibration or mechanical stress.
• Scoop-Proof Design: Prevents damage during mating and unmating, enhancing the longevity and reliability of the connectors.
• Non-Release Plug with Grounding Ring: Provides additional safety and stability, ensuring that the electrical connection remains intact even under challenging conditions.
• High-Temperature Operation: Capable of continuous operation at temperatures of 175 °C or 200 °C, suitable for demanding aerospace environments.

Technical Specifications

This standard is documented in a comprehensive 12-page guide, providing detailed specifications and guidelines for the implementation of these connectors in aerospace systems. The document was released on February 28, 2015, and is identified by the ISBN 978 0 580 87967 8.

Why Choose BS EN 3645-008:2015?

The BS EN 3645-008:2015 standard is a critical resource for aerospace engineers and manufacturers. It ensures that electrical connectors meet stringent safety and performance criteria, which are essential for the reliability and efficiency of aerospace systems. By adhering to this standard, you can be confident that your connectors will perform optimally in high-stress environments, reducing the risk of failure and enhancing the overall safety of your aerospace applications.

Applications

These connectors are specifically designed for use in the aerospace industry, where they are employed in a variety of applications, including:

• Aircraft electrical systems
• Avionics and instrumentation
• Satellite and space exploration equipment
• Military and defense systems

Compliance and Quality Assurance

Compliance with the BS EN 3645-008:2015 standard ensures that your connectors are manufactured to the highest quality standards, providing peace of mind and assurance of performance. This standard is recognized internationally, making it a valuable asset for companies operating in the global aerospace market.

Conclusion

In the fast-paced and demanding world of aerospace technology, the BS EN 3645-008:2015 standard is an indispensable tool for ensuring the reliability and safety of electrical connectors. With its focus on high-temperature operation, secure coupling, and scoop-proof design, this standard provides a comprehensive framework for the development and implementation of top-tier aerospace connectors.

Invest in the BS EN 3645-008:2015 standard to elevate your aerospace projects to new heights of excellence and reliability. Ensure that your systems are equipped with connectors that meet the rigorous demands of the industry, providing unmatched performance and safety.

BS EN 3645-008:2015

This standard BS EN 3645-008:2015 Aerospace series. Connectors, electrical, circular, scoop-proof, triple start threaded coupling operating temperature 175 °C or 200 °C continuous is classified in these ICS categories:

• 49.060 Aerospace electric equipment and systems

This European Standard specifies the characteristics of plugs with grounding rings in the family of circular, electrical connectors, with triple start threaded coupling.

It applies to models in Table 2.

For contacts, sealing plugs and cable outlet accessories associated with this plug see EN 3645‑002 . For receptacles and protective covers, see EN 3645‑003 , EN 3645‑004 , EN 3645‑005 , EN 3645‑007 , EN 3645‑009 and EN 3645‑010 respectively.

These connectors are derived from and interchangeable with models W, J, K, F, M and Z in specification MIL-DTL-38999/26.
