BS EN 3646-004:2015 Aerospace Series Connectors

Welcome to the world of advanced aerospace technology with the BS EN 3646-004:2015 Aerospace Series Connectors. This product standard is a testament to the precision and reliability required in the aerospace industry, ensuring that every connection is secure and efficient.

Product Overview

The BS EN 3646-004:2015 standard specifies the requirements for electrical connectors used in the aerospace industry. These connectors are circular in shape and feature a bayonet coupling mechanism, which is renowned for its quick and secure connection capabilities. Designed to operate at high temperatures, these connectors can withstand continuous operating temperatures of either 175 °C or 200 °C, making them ideal for demanding aerospace applications.

Key Features

• Standard Number: BS EN 3646-004:2015
• Pages: 14
• Release Date: November 30, 2015
• ISBN: 978 0 580 89602 6
• Status: Standard

Design and Functionality

The design of these connectors is focused on providing a reliable and efficient connection in the challenging environments of aerospace applications. The circular design ensures a compact and robust connection, while the bayonet coupling mechanism allows for quick and easy assembly and disassembly. This is particularly beneficial in situations where time and efficiency are critical.

Temperature Resilience

One of the standout features of the BS EN 3646-004:2015 connectors is their ability to operate continuously at high temperatures. With options for 175 °C or 200 °C, these connectors are built to perform in extreme conditions, ensuring that electrical connections remain stable and secure even in the most demanding environments.

Applications in Aerospace

These connectors are specifically designed for use in the aerospace industry, where reliability and performance are paramount. They are suitable for a wide range of applications, including:

• Aircraft electrical systems
• Avionics
• Satellite communications
• Military aerospace applications

Jam-Nut Mounting

The jam-nut mounting feature of these connectors provides a secure and stable installation, ensuring that the connectors remain firmly in place even under vibration and mechanical stress. This is crucial in aerospace applications, where stability and reliability are essential.

Why Choose BS EN 3646-004:2015?

Choosing the BS EN 3646-004:2015 standard connectors means opting for a product that meets the rigorous demands of the aerospace industry. With a focus on high-temperature performance, secure connections, and ease of use, these connectors are an excellent choice for any aerospace application.

Compliance and Standards

As a product standard, BS EN 3646-004:2015 ensures compliance with industry regulations and standards, providing peace of mind that your electrical connections are up to the task. This standard is recognized and respected across the aerospace industry, making it a reliable choice for professionals and engineers.

Conclusion

In the fast-paced and demanding world of aerospace, having reliable and efficient electrical connectors is crucial. The BS EN 3646-004:2015 Aerospace Series Connectors offer the perfect solution, combining high-temperature resilience, secure bayonet coupling, and robust jam-nut mounting. Whether you're working on aircraft, satellites, or military applications, these connectors provide the performance and reliability you need.

Invest in the BS EN 3646-004:2015 standard connectors and ensure your aerospace projects are equipped with the best in electrical connection technology.

BS EN 3646-004:2015

This standard BS EN 3646-004:2015 Aerospace series. Connectors, electrical, circular, bayonet coupling, operating temperature 175 °C or 200 °C continuous is classified in these ICS categories:

• 49.060 Aerospace electric equipment and systems

This Standard defines the characteristics of the jam-nut mounted receptacles of the family of bayonet coupling circular connectors, intended for use in an operating temperature range of –65 °C to 175 °C or 200 °C continuous.

It applies to models defined in Table 4.

For contact, filler plugs and rear accessories associated with this receptacle see EN 3646-002 . For plugs and protective covers see EN 3646-008 and EN 3646-009 respectively.
