BS EN 3646-009:2015 Aerospace Series Connectors

Introducing the BS EN 3646-009:2015, a pivotal standard in the aerospace industry, designed to ensure the highest level of performance and reliability for electrical connectors. This standard is essential for professionals seeking to maintain excellence in aerospace engineering and design.

Product Overview

The BS EN 3646-009:2015 standard specifies the requirements for circular electrical connectors with bayonet coupling, which are capable of operating at continuous temperatures of 175°C or 200°C. These connectors are integral to the aerospace industry, providing robust and reliable connections in demanding environments.

Key Features

• Standard Number: BS EN 3646-009:2015
• Pages: 12
• Release Date: June 30, 2015
• ISBN: 978 0 580 88149 7
• Status: Standard

Why Choose BS EN 3646-009:2015?

This standard is a critical component for any aerospace project requiring reliable electrical connections. The bayonet coupling design ensures a secure and quick connection, which is vital in high-stakes environments where performance cannot be compromised. The ability to operate continuously at high temperatures makes these connectors suitable for a wide range of aerospace applications, from commercial aircraft to military jets.

Applications

The BS EN 3646-009:2015 standard is applicable in various aerospace sectors, including:

• Commercial Aviation
• Military Aircraft
• Spacecraft
• Unmanned Aerial Vehicles (UAVs)

Technical Specifications

Designed to withstand the rigors of aerospace environments, these connectors are engineered for durability and reliability. The protective cover for the receptacle ensures that the connectors remain free from dust and debris, maintaining optimal performance over time.

Temperature Resistance

With an operating temperature range of 175°C to 200°C, these connectors are built to perform under extreme conditions. This makes them ideal for use in high-temperature environments where other connectors might fail.

Bayonet Coupling

The bayonet coupling mechanism provides a secure and reliable connection, ensuring that the connectors remain firmly in place even in environments subject to vibration and movement. This feature is particularly important in aerospace applications where stability and reliability are paramount.

Compliance and Standards

The BS EN 3646-009:2015 standard is recognized internationally, ensuring that your aerospace projects meet global compliance requirements. Adhering to this standard not only guarantees quality and reliability but also facilitates international collaboration and trade.

Global Recognition

As a widely recognized standard, BS EN 3646-009:2015 is trusted by aerospace professionals around the world. Its adoption ensures that your projects are aligned with the latest industry practices and technological advancements.

Conclusion

In the fast-paced and demanding world of aerospace engineering, the BS EN 3646-009:2015 standard provides the assurance of quality and reliability that professionals need. Whether you are designing new aircraft or maintaining existing fleets, this standard is an invaluable resource that supports the highest levels of performance and safety.

Invest in the BS EN 3646-009:2015 standard to ensure that your aerospace connectors meet the rigorous demands of the industry, providing peace of mind and confidence in your engineering solutions.

BS EN 3646-009:2015

This standard BS EN 3646-009:2015 Aerospace series. Connectors, electrical, circular, bayonet coupling, operating temperature 175°C or 200°C continuous is classified in these ICS categories:

• 49.060 Aerospace electric equipment and systems

This European Standard defines the characteristics of protective covers for receptacles in the family of bayonet coupling circular connectors, intended for use in an operating temperature range of – 65 °C to 175 °C or 200 °C continuous.

It applies to models defined in Table 2.

For receptacles associated with these protective covers, see EN 3646-003 to EN 3646-007.
