BS EN 4156:2013

This standard BS EN 4156:2013 Aerospace series. Rod ends, with self-aligning double row ball bearings and threaded shank in steel. Inner ring and balls in corrosion resisting steel. Dimensions and loads. Inch series is classified in these ICS categories:

• 49.035 Components for aerospace construction

This European Standard specifies the characteristics of adjustable rod ends with self-aligning double row ball bearing and threaded shank in steel, inner ring and balls in corrosion resisting steel.

They consist of:

• a rod end comprising:

  • either seals or shields;

  • an optional longitudinal groove for locking purpose;

• an inner ring with balls.

These rod ends are intended for use with flight control rods or rods for aerospace structures.

They are intended to be used in the temperature range: – 54 °C to 150 °C.

However, being lubricated with the following greases:

• very high pressure grease, ester type (code A), operational range – 73 °C to 121 °C according MIL-PRF-23827 type II

• very high pressure grease, synthetic hydrocarbons, general purpose (code B), operational range − 54 °C to 177 °C (see EN 2067), according MIL-PRF-81322.

• very high pressure grease, lithium type (code C) operational range – 73 °C to 121 °C according MIL-PRF-23827 type I.

Their field of application when lubricated with codes A and C grease is limited to 121 °C.
