BS EN 4604-007:2019 Aerospace Series Coaxial Cable

Introducing the BS EN 4604-007:2019, a top-tier product standard in the aerospace industry, specifically designed for electrical signal transmission. This standard pertains to a coaxial cable that is engineered to meet the rigorous demands of aerospace applications, ensuring reliable performance and durability in extreme conditions.

Key Features

• Standard Number: BS EN 4604-007:2019
• Pages: 14
• Release Date: May 20, 2020
• ISBN: 978 0 539 13630 2
• Status: Standard

Product Overview

The BS EN 4604-007:2019 standard is a comprehensive guideline for the manufacturing and application of coaxial cables used in aerospace signal transmission. This specific type, known as Type WN, is designed to operate efficiently at a characteristic impedance of 50 ohms and can withstand temperatures up to 200 °C. This makes it an ideal choice for environments where high performance and reliability are critical.

Why Choose This Coaxial Cable?

In the aerospace industry, the need for reliable and efficient signal transmission is paramount. The BS EN 4604-007:2019 standard ensures that the coaxial cables produced under its guidelines are capable of delivering exceptional performance. Here are some reasons why this product stands out:

• High Temperature Resistance: With a maximum operating temperature of 200 °C, this cable is suitable for high-temperature environments, ensuring consistent performance without degradation.
• Optimal Impedance: The 50-ohm impedance is ideal for minimizing signal loss and ensuring efficient transmission, which is crucial in aerospace applications where precision is key.
• Durability: Designed to withstand the harsh conditions of aerospace environments, this cable offers long-lasting durability and reliability.
• Compliance with Industry Standards: As a product standard, it ensures that the cable meets all necessary industry regulations and quality benchmarks.

Applications

This coaxial cable is specifically designed for use in the aerospace industry, where it can be employed in a variety of applications, including:

• Signal transmission in aircraft systems
• Communication systems in aerospace vehicles
• Data transmission in high-temperature environments
• Any application requiring high reliability and performance in signal transmission

Technical Specifications

The BS EN 4604-007:2019 standard provides detailed specifications to ensure that the coaxial cable meets the highest quality and performance standards. These specifications include:

• Impedance: 50 ohms
• Temperature Rating: Up to 200 °C
• Type: WN

Conclusion

The BS EN 4604-007:2019 Aerospace Series Coaxial Cable is an essential component for any aerospace application requiring reliable and efficient signal transmission. Its high-temperature resistance, optimal impedance, and compliance with industry standards make it a superior choice for engineers and manufacturers in the aerospace sector. By choosing this product, you are ensuring that your systems are equipped with a cable that meets the highest standards of quality and performance.

For more detailed information on the specifications and applications of this product, please refer to the full standard document, which provides comprehensive guidelines and technical details.

BS EN 4604-007:2019

This standard BS EN 4604-007:2019 Aerospace series. Cable, electrical, for signal transmission is classified in these ICS categories:

• 49.060 Aerospace electric equipment and systems

This document specifies the required characteristics of a coaxial cable, 50 Ω, type WN, for use in aircraft electrical systems at operating temperature between − 55 °C and 200 °C and especially for high frequency up to 6 GHz.
