BS EN 4612-012:2019 Aerospace Series Cables

Introducing the BS EN 4612-012:2019 Aerospace Series Cables, a product standard that sets the benchmark for electrical cables used in aerospace applications. This standard is essential for professionals in the aerospace industry who require reliable and high-performance cables for both single and multicore assembly. Designed to meet the rigorous demands of aerospace environments, these cables are part of the XLETFE Family, known for their exceptional durability and performance.

Key Features

• Standard Number: BS EN 4612-012:2019
• Pages: 16
• Release Date: October 25, 2019
• ISBN: 978 0 539 07001 9
• Status: Standard

Product Description

The BS EN 4612-012:2019 standard specifies the requirements for electrical cables used in general-purpose aerospace applications. These cables are designed to operate efficiently in a wide range of temperatures, from as low as -65 °C to as high as 150 °C, making them suitable for various aerospace environments. The cables feature a dual extruded wall construction, providing enhanced protection and durability for open applications.

One of the standout features of these cables is their construction using nickel-plated copper, which offers excellent conductivity and resistance to corrosion. This makes them ideal for use in harsh aerospace conditions where reliability is paramount. The cables are available in both jacketed and screened, as well as jacketed configurations, providing flexibility in their application.

Advanced Construction

The dual extruded wall design of these cables ensures superior mechanical strength and protection against environmental factors. The outer jacket provides an additional layer of defense against physical damage, while the screen (braid) offers electromagnetic interference (EMI) shielding, ensuring signal integrity in sensitive aerospace systems.

Moreover, the cables are UV laser printable, allowing for easy identification and traceability. This feature is particularly beneficial in complex aerospace systems where accurate cable identification is crucial for maintenance and troubleshooting.

Applications

The BS EN 4612-012:2019 standard is applicable to a wide range of aerospace applications, including:

• Aircraft electrical systems
• Avionics and instrumentation
• Satellite and space exploration equipment
• Military and defense systems
• Commercial aviation

These cables are designed to meet the stringent requirements of the aerospace industry, ensuring reliable performance in critical applications. Their robust construction and high-temperature tolerance make them suitable for use in both commercial and military aerospace systems.

Why Choose BS EN 4612-012:2019 Cables?

Choosing the right cables for aerospace applications is crucial for ensuring the safety and reliability of the entire system. The BS EN 4612-012:2019 standard provides a comprehensive framework for selecting cables that meet the highest industry standards. By adhering to this standard, aerospace professionals can be confident in the quality and performance of their electrical systems.

These cables are not only designed to withstand extreme temperatures and environmental conditions but also offer excellent electrical performance. The use of nickel-plated copper ensures optimal conductivity, while the dual extruded wall construction provides superior protection against mechanical and environmental stressors.

Conclusion

In summary, the BS EN 4612-012:2019 Aerospace Series Cables are an essential component for any aerospace application requiring reliable and high-performance electrical systems. With their advanced construction, wide temperature range, and UV laser printability, these cables offer unparalleled performance and durability. Whether for commercial aviation, military applications, or space exploration, these cables are designed to meet the most demanding requirements of the aerospace industry.

Invest in the BS EN 4612-012:2019 standard cables to ensure your aerospace systems are equipped with the best in class electrical components, providing peace of mind and reliability in every mission.

BS EN 4612-012:2019

This standard BS EN 4612-012:2019 Aerospace series. Cables, electrical, for general purpose, single and multicore assembly. XLETFE Family. Jacketed or screened and jacketed is classified in these ICS categories:

• 49.060 Aerospace electric equipment and systems

This document specifies the characteristics of UV laser printable jacket, nickel plated copper conductor, electrical cables crosslinked ethylene tetra fluoro ethylene co-polymer (XLETFE) family for use in the on-board electrical systems of aircraft at operating temperatures between – 65 °C and 150 °C, operating at voltages not exceeding 600 V rms. This insulation system has been used in aerospace applications using 115 V (phase-to-neutral) 400 Hz ac and 28 Vdc. Verification of the suitability of cables for use on other electrical systems is the responsibility of the user.

These cables are suitable for airframe use without additional protection. In case of conflict between this document and other referenced documents the requirements of this document shall take precedence.
