BS EN 4644-013:2015 Aerospace Series Connector

The BS EN 4644-013:2015 is a pivotal standard in the aerospace industry, providing comprehensive guidelines for electrical and optical connectors. This standard is essential for professionals seeking reliable and efficient solutions in aerospace applications. With its focus on modular, rectangular inserts, this product standard ensures optimal performance and safety in demanding environments.

Key Features

• Standard Number: BS EN 4644-013:2015
• Pages: 12
• Release Date: December 31, 2015
• ISBN: 978 0 580 89853 2
• Status: Standard

Product Overview

This standard is part of the Aerospace series, specifically designed for connectors that are both electrical and optical. The connectors are rectangular and modular, featuring rectangular inserts that are engineered to operate continuously at temperatures of 175 °C or 125 °C. This makes them suitable for a wide range of aerospace applications where temperature resilience is crucial.

Design and Functionality

The connectors described in this standard are size 1 plugs, equipped with a ground block. Notably, they are designed without mounting holes, which allows for greater flexibility in installation and integration into various systems. The connectors are classified under class B and F, indicating their suitability for specific operational environments and conditions.

Temperature Resilience

One of the standout features of the BS EN 4644-013:2015 standard is its emphasis on temperature resilience. The connectors are capable of continuous operation at high temperatures, specifically 175 °C or 125 °C. This makes them ideal for aerospace applications where extreme temperatures are a common challenge.

Applications

The BS EN 4644-013:2015 standard is applicable in a variety of aerospace contexts, including:

• Aircraft electrical systems
• Optical data transmission in aerospace environments
• High-temperature applications requiring reliable connectivity
• Modular systems where flexibility and adaptability are required

Why Choose BS EN 4644-013:2015?

Choosing the BS EN 4644-013:2015 standard ensures that you are adhering to the highest levels of quality and safety in aerospace connector technology. This standard is meticulously crafted to meet the rigorous demands of the aerospace industry, providing peace of mind and assurance of performance.

Reliability and Safety

With its robust design and high-temperature capabilities, this standard guarantees reliable performance in critical aerospace applications. The absence of mounting holes allows for versatile use, while the inclusion of a ground block enhances safety and stability in electrical connections.

Comprehensive Guidelines

Spanning 12 pages, the BS EN 4644-013:2015 standard offers detailed guidelines and specifications, ensuring that all aspects of connector design and application are covered. This comprehensive approach facilitates ease of implementation and adherence to industry best practices.

Conclusion

The BS EN 4644-013:2015 Aerospace Series Connector standard is an indispensable resource for professionals in the aerospace industry. Its focus on high-temperature operation, modular design, and comprehensive guidelines make it a top choice for ensuring reliable and efficient connectivity in demanding environments. By adhering to this standard, you are investing in quality, safety, and performance.

BS EN 4644-013:2015

This standard BS EN 4644-013:2015 Aerospace series. Connector, electrical and optical, rectangular, modular, rectangular inserts, operating temperature 175 °C (or 125 °C) continuous is classified in these ICS categories:

• 49.090 On-board equipment and instruments
• 49.060 Aerospace electric equipment and systems

This European Standard specifies the size 1 plug with ground block for disconnect applications used in the family of modular rectangular electrical and optical connector with rectangular inserts. The receptacle corresponding to this plug is defined in EN 4644-012 and EN 4644-014.
