BS EN 50264-2-2:2008
Railway applications. Railway rolling stock power and control cables having special fire performance Cables with crosslinked elastomeric insulation. Multicore cables
Standard number: | BS EN 50264-2-2:2008 |
Pages: | 32 |
Released: | 2008-08-29 |
ISBN: | 978 0 580 64072 8 |
Status: | Standard |
BS EN 50264-2-2:2008
This standard BS EN 50264-2-2:2008 Railway applications. Railway rolling stock power and control cables having special fire performance is classified in these ICS categories:
- 13.220.20 Fire protection
- 29.060.20 Cables
- 45.060.01 Railway rolling stock in general
EN 50264-2-2 specifies requirements for, and constructions and dimensions of, multicore cables of the following types and voltage ratings:
300/500 V screened or unscreened (1 mm2, 1,5 mm2 and 2,5 mm2, number of cores from 2 to 40);
0,6/1 kV screened or unscreened (1,5 mm2 to 50 mm2, 2, 3 and 4 cores).
NOTE Not all conductor sizes or number of cores are specified for every type.
All cables have class 5 tinned copper conductors to EN 60228, halogen-free insulation and halogen-free sheath. They are for use in railway rolling stock as fixed wiring, or wiring where limited flexing in operation is encountered. The requirements provide for a continuous conductor temperature not exceeding 90 °C and a maximum temperature for short circuit conditions of 200 °C based on a duration of 5 s.
Under fire conditions the cables exhibit special performance characteristics in respect of maximum permissible flame propagation (flame spread) and maximum permissible emission of smoke and toxic gases.
EN 50264-2-2 should be read in conjunction with Part 1 “General requirements”.
