BS EN 55014-2:2015

This standard BS EN 55014-2:2015 Electromagnetic compatibility. Requirements for household appliances, electric tools and similar apparatus is classified in these ICS categories:

• 33.100.20 Immunity
• 25.140.20 Electric tools
• 33.100.01 Electromagnetic compatibility in general
• 97.030 Domestic electrical appliances in general

1.1 This part of CISPR 14 deals with the electromagnetic immunity of appliances and similar apparatus for household and similar purposes that use electricity, as well as electric toys and electric tools, the rated voltage of the apparatus being not more than 250 V for single-phase apparatus to be connected to phase and neutral, and 480 V for other apparatus.

Apparatus may incorporate motors, heating elements or their combination, may contain electric or electronic circuitry, and may be powered by the mains, by transformer, by batteries, or by any other electrical power source.

Apparatus not intended for household use, but which nevertheless may require the immunity level, such as apparatus intended to be used by laymen in shops, in light industry and on farms, are within the scope of this standard, as far as they are included in CISPR 14‑1 . In addition, the following are also included in the scope of this standard:

• microwave ovens for domestic use and catering;

• cooking hobs and cooking ovens, heated by means of r.f. energy;

• (single- and multiple-zone) induction cooking appliances;

• appliances for personal care equipped with radiators in the range from UV to IR, inclusive (this includes visible light);

• power supplies and battery chargers provided with or intended for apparatus within the scope of this standard.

1.2 This standard does not apply to:

• equipment for lighting purposes;

• apparatus designed exclusively for heavy industrial purposes;

• apparatus intended to be part of the fixed electrical installation of buildings (such as fuses, circuit breakers, cables and switches);

• apparatus intended to be used in locations where special electromagnetic conditions prevail, such as the presence of high electromagnetic fields (for example in the vicinity of a broadcast transmitting station), or where high pulses occur on the power network (such as in a power generator station);

• radio and television receivers, audio and video equipment, and electronic music instruments other than toys;

• medical electrical appliances;

• personal computers and similar equipment other than toys;

• radio transmitters;

• apparatus designed to be used exclusively in vehicles;

• babies surveillance systems.

1.3 Immunity requirements in the frequency range 0 Hz to 400 GHz are covered.

1.4 The effects of electromagnetic phenomena relating to the safety of apparatus are excluded from this standard and are covered by other standards, for example in the IEC 60335 series.

Abnormal operation of the apparatus (such as simulated faults in the electric circuitry for testing purposes) is not taken into consideration.

1.5 The object of this standard is to specify the immunity requirements for apparatus defined in the scope in relation to continuous and transient, conducted and radiated electromagnetic disturbances, including electrostatic discharges.

These requirements represent essential electromagnetic compatibility immunity requirements.
