BS EN 60079-30-1:2017

Explosive atmospheres Electrical resistance trace heating. General and testing requirements

English Secure PDF

Immediate download

399.30 EUR

You can read the standard for 1 hour. More information in the category: E-reading

Reading the standard

for 1 hour

39.93 EUR

You can read the standard for 24 hours. More information in the category: E-reading

Reading the standard

for 24 hours

119.79 EUR

English Hardcopy

In stock

399.30 EUR

Standard number:	BS EN 60079-30-1:2017
Pages:	74
Released:	2017-07-31
ISBN:	978 0 580 79820 7
Status:	Standard

DESCRIPTION

BS EN 60079-30-1:2017

This standard BS EN 60079-30-1:2017 Explosive atmospheres is classified in these ICS categories:

29.260.20 Electrical apparatus for explosive atmospheres

This part of IEC 60079 specifies general and testing requirements for electrical resistance trace heaters for application in explosive atmospheres with the exclusion of those for EPL Ga and Da. This standard covers trace heaters that comprise either factory or field (work-site) assembled units, and which may be series trace heaters, parallel trace heaters, trace heater pads, or trace heater panels that have been assembled and/or terminated in accordance with the manufacturer’s instructions.

This standard also includes requirements for termination assemblies and control methods used with trace heating systems. The explosive atmospheres referred to in this standard are those defined in IEC 60079-10-1 and IEC 60079-10-2 .

Text deleted

This standard supplements and modifies the general requirements of IEC 60079-0 , except as indicated in Table 1. Where a requirement of this standard conflicts with a requirement of IEC 60079-0 , the requirement of this standard takes precedence.

Table 1

Application or exclusion of specific clauses of IEC 60079-0

IEC 60079-0		Electrical resistance trace heaters and integral components		Terminations as separate components
Ed. 6.0 (2011) (informative)	Clause / Subclause title (normative)	Group I and Group II	Group III	Terminations as separate components
1	Scope	Applies	Applies	Applies
2	Normative references	Applies	Applies	Applies
3	Terms and definitions	Applies, except ambient temperature, see 3.1	Applies, except ambient temperature, see 3.1	Applies, except ambient temperature, see 3.1
4	Equipment grouping	Applies	Applies	Applies
4.1	Group I	Applies	Excluded	Applies
4.2	Group II	Applies, always IIC	Excluded	Applies
4.3	Group III	Excluded	Applies, outside of thermal insulation only, always IIIC	Applies, outside of thermal insulation only
4.4	Equipment for a particular explosive atmosphere	Excluded	Excluded	Applies
5.1	Environmental influences	Applies	Applies	Applies
5.1.1	Ambient temperature	Replaced by 6.1e)	Replaced by 6.1e)	Applies, see 3.1
5.1.2	External source of heating or cooling	Applies	Applies	Applies
5.2	Service temperature	Modified	Modified	Applies
5.3.1	Determination of maximum surface temperature	Replaced by 4.5 in conjunction with 5.1.13	Replaced by 4.5 in conjunction with 5.1.13 only when tested in accordance with 5.1.13.3.	Applies
5.3.2.1	Group I electrical equipment	Applies	Excluded	Applies
5.3.2.2	Group II electrical equipment	Applies	Excluded	Applies
5.3.2.3.1	Group III electrical equipment, Maximum surface temperature determined without a dust layer	Excluded	Applies, where the maximum sheath temperatures determined by IEC/IEEE 60079-30-1 are used in place of the method for temperature determination from IEC 60079-0 .	Applies
5.3.2.3.2	Group III electrical equipment Maximum surface temperature with respect to dust layers	Excluded	Applies, where the maximum sheath temperature is determined only for those surfaces that are specified to be exposed to layers of combustible dust. Does not apply for trace heaters specified to be covered by thermal insulation.	Applies
5.3.3	Small component temperature for Group I and Group II electrical equipment	Excluded	Excluded	Applies
6.1	Requirements for all electrical equipment — General	Applies	Applies	Applies
6.2	Mechanical strength	Replaced by 4.2	Replaced by 4.2	When in direct contact with the trace heater, may be substituted by 4.2
6.3	Opening times	Excluded	Excluded	Applies
6.4	Circulating currents in enclosures (e.g. of large electrical machines)	Excluded	Excluded	Excluded
6.5	Gasket retention	Excluded	Excluded	Applies
6.6	Electromagnetic and ultrasonic radiating equipment	Excluded	Excluded	Applies
7.1.1	Non-metallic enclosures and non-metallic parts of enclosures — Applicability	Replaced by the last paragraph of 4.1	Replaced by the last paragraph of 4.1	Applies
7.1.2.1	Specification of materials, General	Replaced by the last paragraph of 4.1	Replaced by the last paragraph of 4.1	Applies
7.1.2.2	Specification of materials, plastic materials	Replaced by the last paragraph of 4.1	Replaced by the last paragraph of 4.1	Applies
7.1.2.3	Elastomers	Replaced by the last paragraph of 4.1	Replaced by the last paragraph of 4.1	Applies
7.2	Thermal endurance	Replaced by requirements and tests	Replaced by requirements and	Applies
		of this standard	tests of this standard
7.3	Resistance to light	Replaced by 5.1.16 for trace heaters and integral components specified for outdoor exposure	Replaced by 5.1.16 for trace heaters and integral components specified for outdoor exposure	Applies
7.4.1	Electrostatic charges on external non-metallic materials, Applicability	Excluded	Excluded	Applies
7.4.2	Avoidance of a build-up of electrostatic charge on Group I or Group II electrical equipment	Excluded	Excluded	Applies
7.4.3	Avoidance of a build-up of electrostatic charge on equipment for Group III	Excluded	Excluded	Applies
7.5	Accessible metal parts	Excluded	Excluded	Applies
8.1	Material composition	Excluded	Excluded	Applies
8.2	Group I	Excluded	Excluded	Applies
8.3	Group II	Excluded	Excluded	Applies
8.4	Group III	Excluded	Excluded	Applies
9	Fasteners	Excluded	Excluded	Applies
10	Interlocking devices	Excluded	Excluded	Applies
11	Bushings	Excluded	Excluded	Applies
12	Materials used for cementing	Replaced by the last paragraph of 4.1	Replaced by the last paragraph of 4.1	Applies
13	Ex Components	Applies	Applies	Applies
14	Connection facilities and termination compartments	Covered by the requirements of this standard	Covered by the requirements of this standard	Applies
15	Connection facilities for earthing and bonding conductors	Replaced by 5.1.15	Replaced by 5.1.15	Applies
15	Entries into enclosures	Excluded	Excluded	Applies
17	Supplementary requirements for rotating electrical machines	Excluded	Excluded	Excluded
18	Supplementary requirements for switchgear	Excluded	Excluded	Excluded
19	Supplementary requirements for fuses	Excluded	Excluded	Applies
20	Supplementary requirements for plugs and sockets	Excluded	Excluded	Applies
21	Supplementary requirements for luminaires	Excluded	Excluded	Excluded
22	Supplementary requirements for caplights and handlights	Excluded	Excluded	Excluded
23	Equipment incorporating cells and batteries	Excluded	Excluded	Applies
24	Documentation	Applies	Applies	Applies
25	Compliance of prototype or	Applies	Applies	Applies
	sample with documents
26.1	General	Applies	Applies	Applies
26.2	Test configuration	Applies	Applies.	Applies
26.3	Tests in explosive test mixtures	Excluded	Excluded	Applies
26.4	Tests of enclosures	Excluded	Excluded	Applies
26.4.1	Order of tests	Excluded	Excluded	Applies
26.4.1.1	Metallic enclosures, metallic parts of enclosures and glass parts of enclosures	Excluded	Excluded	Applies
26.4.1.2	Non-metallic enclosures or non-metallic parts of enclosures	Excluded	Excluded	Applies
26.4.2	Resistance to impact	Replaced by 5.1.5	Replaced by 5.1.5	Applies
26.4.3	Drop test	Excluded	Excluded	Excluded
26.4.4	Acceptance criteria	Replaced by 5.1.5	Replaced by 5.1.5	Applies
26.4.5	Degree of protection by enclosure	Replaced by 5.1.8 and/or 5.1.9	Replaced by 5.1.8 and/or 5.1.9.	Applies
26.5	Thermal tests	Modified.	Modified	Applies
26.5.1	Temperature measurement	Replaced by 5.1.13	Replaced by 5.1.13	Applies
26.5.2	Thermal shock test	Excluded	Excluded	Applies
26.5.3	Small component ignition test	Excluded	Excluded	Applies
26.6	Torque test for bushings	Excluded	Excluded	Applies
26.7	Non-metallic enclosures or non-metallic parts of enclosures	Excluded	Excluded	Applies
26.8	Thermal endurance to heat	Replaced by 5.1.11	Replaced by 5.1.11	Applies
26.9	Thermal endurance to cold	Replaced by 5.1.7	Replaced by 5.1.7	Applies
26.10	Resistance to light	Replaced by 5.1.16for trace heaters and integral components specified for outdoor exposure	Replaced by 5.1.16 for trace heaters and integral components specified for outdoor exposure	Applies
26.11	Resistance to chemical agents for Group I electrical equipment	Applies for Group I	Excluded	Applies
26.12	Earth continuity	Excluded	Excluded	Applies
26.13	Surface resistance test of parts of enclosures of non-metallic materials	Excluded	Excluded	Applies
26.14	Measurement of capacitance	Excluded	Excluded	Applies
26.15	Verification of ratings of ventilating fans	Excluded	Excluded	Excluded
26.16	Alternative qualification of elastomeric sealing O-rings	Excluded	Excluded	Applies
27	Routine tests	Applies	Applies	Applies
28	Manufacturers responsibility	Applies	Applies	Applies
29	Marking	Modified	Modified	Applies
30	Instructions	Modified	Modified	Applies
Annex A	Supplementary requirements for Ex cable glands	Excluded	Excluded	Applies
Annex B	Requirements for Ex components	Excluded	Excluded	Applies
Annex C	Example of rig for resistance to impact test	Replaced by 5.1.5	Replaced by 5.1.5	Applies
Annex D	Motors supplied by converters	Excluded	Excluded	Excluded
Annex E	Temperature rise testing of electric machines	Excluded	Excluded	Excluded
Annex E	Guideline flowchart for tests of non-metallic enclosures or non-metallic parts of enclosures (26.4)	Excluded	Excluded	Applies

NOTE 1

Clause numbers in the three right-hand columns of this table refer to IEC/IEEE 60079-30-1

NOTE 2

The clause number in the above table is shown for information only. The applicable requirements of IEC 60079-0 are identified by the clause title which is normative.

Applies: this requirement of IEC 60079-0 is applied without change.

Excluded: this requirement of IEC 60079-0 does not apply.

Modified: this requirement of IEC 60079-0 is modified as detailed in this standard.
