BS EN 60191-6-6:2001

Name: BS EN 60191-6-6:2001 Mechanical standardization of semiconductor devices. General rules for the preparation of outline drawings of surface mounted semiconductor device packages Design guide for fine pitch land grid array (FLGA)
SKU: i449_BS EN 60191-6-6:2001
Price: 191.18 EUR
Availability: InStock

Mechanical standardization of semiconductor devices. General rules for the preparation of outline drawings of surface mounted semiconductor device packages Design guide for fine pitch land grid array (FLGA)

English Secure PDF

Immediate download

191.18 EUR

You can read the standard for 1 hour. More information in the category: E-reading

Reading the standard

for 1 hour

19.12 EUR

You can read the standard for 24 hours. More information in the category: E-reading

Reading the standard

for 24 hours

57.35 EUR

English Hardcopy

In stock

191.18 EUR

Standard number:	BS EN 60191-6-6:2001
Pages:	16
Released:	2001-09-05
ISBN:	0 580 38393 8
Status:	Standard

DESCRIPTION

BS EN 60191-6-6:2001

This standard BS EN 60191-6-6:2001 Mechanical standardization of semiconductor devices. General rules for the preparation of outline drawings of surface mounted semiconductor device packages is classified in these ICS categories:

01.100.25 Electrical and electronics engineering drawings
31.080.01 Semiconductor devices in general

IEC 60191-6-6:2001 provides common outline drawings and dimensions for all types of structures and composed materials of fine-pitch land grid array (hereinafter called FLGA) whose terminal pitch is less than, or equal to, 0,80 mm and whose package body outline is square.
