immediate downloadReleased: 2012-04-30
BS EN 60297-3-107:2012 Mechanical structures for electronic equipment. Dimensions of mechanical structures of the 482,6 mm (19 in) series Dimensions of subracks and plug-in units, small form factor

BS EN 60297-3-107:2012

Mechanical structures for electronic equipment. Dimensions of mechanical structures of the 482,6 mm (19 in) series Dimensions of subracks and plug-in units, small form factor

Format
Availability
Price and currency
English Secure PDF
Immediate download
312.18 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
31.22 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
93.65 EUR
English Hardcopy
In stock
312.18 EUR
Standard number:BS EN 60297-3-107:2012
Pages:38
Released:2012-04-30
ISBN:978 0 580 68232 2
Status:Standard
DESCRIPTION

BS EN 60297-3-107:2012


This standard BS EN 60297-3-107:2012 Mechanical structures for electronic equipment. Dimensions of mechanical structures of the 482,6 mm (19 in) series is classified in these ICS categories:
  • 31.240 Mechanical structures for electronic equipment
IEC 60297-3-107:2012 defines the interface dimensions between subracks and associated plug-in units using connectors as defined in PICMG-MTCA.0 (Fixed board, see Figure 7) and IEC 61076-4-116 (Two part, see Figure 12) and other two part connectors, (see Figure 15). For mechanical and climatic tests refer to IEC 61587-1. For electromagnetic shielding performance tests refer to IEC 61587-3.
