BS EN 60317-23:2014+A1:2019 - Solderable Polyesterimide Enamelled Round Copper Wire, Class 180

Introducing the BS EN 60317-23:2014+A1:2019, a comprehensive standard that sets the benchmark for solderable polyesterimide enamelled round copper wire, class 180. This standard is essential for manufacturers, engineers, and quality assurance professionals who are involved in the production and application of winding wires. With its detailed specifications, this document ensures that your products meet the highest quality and performance standards.

Key Features

• Standard Number: BS EN 60317-23:2014+A1:2019
• Pages: 16
• Release Date: October 9, 2019
• ISBN: 978 0 539 01848 6
• Status: Standard

Why Choose This Standard?

The BS EN 60317-23:2014+A1:2019 standard is a critical resource for ensuring the reliability and efficiency of winding wires used in various electrical applications. Here are some reasons why this standard is indispensable:

• Comprehensive Specifications: This standard provides detailed specifications for solderable polyesterimide enamelled round copper wire, class 180, ensuring that your products meet industry requirements.
• Quality Assurance: By adhering to this standard, manufacturers can guarantee the quality and performance of their winding wires, leading to increased customer satisfaction and reduced product failures.
• Industry Compliance: Compliance with this standard ensures that your products are in line with international regulations, facilitating easier market access and acceptance.
• Enhanced Performance: The specifications outlined in this standard help in producing winding wires that offer superior thermal and mechanical properties, making them suitable for demanding applications.

Applications

The solderable polyesterimide enamelled round copper wire, class 180, is widely used in various applications, including:

• Transformers: Ensures efficient energy transfer and reduces energy losses.
• Motors: Provides reliable performance in both industrial and consumer motors.
• Generators: Enhances the durability and efficiency of generators.
• Inductors: Ideal for use in inductors due to its excellent electrical properties.

Technical Insights

The BS EN 60317-23:2014+A1:2019 standard delves into the technical aspects of winding wires, offering insights into their construction, properties, and testing methods. This ensures that manufacturers have a clear understanding of the requirements and can produce wires that meet the highest standards of quality and performance.

Benefits of Polyesterimide Enamelled Copper Wire

Polyesterimide enamelled copper wire is renowned for its exceptional properties, making it a preferred choice in many electrical applications. Some of its benefits include:

• High Thermal Resistance: Capable of withstanding high temperatures, making it suitable for applications with extreme thermal demands.
• Excellent Mechanical Strength: Offers superior mechanical properties, ensuring durability and longevity.
• Good Solderability: Facilitates easy soldering, enhancing the efficiency of manufacturing processes.
• Electrical Insulation: Provides excellent electrical insulation, reducing the risk of short circuits and electrical failures.

Conclusion

The BS EN 60317-23:2014+A1:2019 standard is an invaluable resource for anyone involved in the production or application of winding wires. By adhering to this standard, you can ensure that your products meet the highest quality and performance standards, providing peace of mind to both manufacturers and end-users. Whether you are looking to enhance the performance of transformers, motors, generators, or inductors, this standard provides the guidance and specifications needed to achieve excellence.

Invest in the BS EN 60317-23:2014+A1:2019 standard today and take the first step towards ensuring the quality and reliability of your winding wires.

BS EN 60317-23:2014+A1:2019

This standard BS EN 60317-23:2014+A1:2019 Specifications for particular types of winding wires is classified in these ICS categories:

• 29.060.10 Wires

This part of IEC 60317 specifies the requirements of solderable enamelled round copper winding wire of class 180 with a sole coating based on polyesterimide resin, which may be modified providing it retains the chemical identity of the original resin and meets all specified wire requirements.

NOTE A modified resin is a resin that has undergone a chemical change, or contains one or more additives to enhance certain performance or application characteristics.

The range of nominal conductor diameters covered by this standard is:

• Grade 1: 0,020 mm up to and including 1,600 mm;

• Grade 2: 0,020 mm up to and including 1,600 mm.

The nominal conductor diameters are specified in Clause 4 of IEC 60317‑0‑1:2013.
