immediate downloadReleased: 2016-02-29
BS EN 60317-31:2016
Specifications for particular types of winding wires Glass fibre wound, resin or varnish impregnated, bare or enamelled rectangular copper wire, temperature index 180
Format
Availability
Price and currency
English Secure PDF
Immediate download
180.00 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
18.00 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
54.00 EUR
English Hardcopy
In stock
180.00 EUR
| Standard number: | BS EN 60317-31:2016 |
| Pages: | 16 |
| Released: | 2016-02-29 |
| ISBN: | 978 0 580 85661 7 |
| Status: | Standard |
DESCRIPTION
BS EN 60317-31:2016
This standard BS EN 60317-31:2016 Specifications for particular types of winding wires is classified in these ICS categories:
- 29.060.10 Wires
This part of IEC 60317 specifies the requirements of glass fibre wound, resin or varnish impregnated, bare or enamelled rectangular copper winding wire, temperature index 180.
NOTE For this type of wire, the heat shock test is inappropriate and therefore a heat shock temperature cannot be established. Consequently, a class based on the requirements for temperature index and heat shock temperature cannot be specified.
The range of nominal conductor dimensions covered by this standard is:
| – | width: | min. | 2,0 mm | max. | 16,0 mm; |
| – | thickness: | min. | 0,80 mm | max. | 5,60 mm. |
The specified combinations of width and thickness as well as the specified width/thickness ratio are according to IEC 60317-0-4.
