BS EN 60512-29-100:2015
Connectors for electronic equipment. Tests and measurements Signal integrity tests up to 500 MHz on M12 style connectors. Tests 29a to 29g
| Standard number: | BS EN 60512-29-100:2015 |
| Pages: | 58 |
| Released: | 2015-11-30 |
| ISBN: | 978 0 580 92481 1 |
| Status: | Standard |
BS EN 60512-29-100:2015
This standard BS EN 60512-29-100:2015 Connectors for electronic equipment. Tests and measurements is classified in these ICS categories:
- 31.220.10 Plug-and-socket devices. Connectors
This part of IEC 60512 specifies the test methods for transmission performance for M12-style connectors up to 500 MHz. It is also suitable for testing lower frequency connectors if they meet the requirements of the detail specifications and of this standard.
All figures show equipment for connectors according to IEC 61076‑2‑109 as an example.
The test methods provided herein are:
-
insertion loss, test 29a;
-
return loss, test 29b;
-
near-end crosstalk (NEXT) test 29c;
-
far-end crosstalk (FEXT), test 29d;
-
transverse conversion loss (TCL), test 29f;
-
transverse conversion transfer loss (TCTL), test 29g.
For the transfer impedance (ZT) test, see IEC 60512‑26‑100, test 26e.
For the coupling attenuation see ISO/IEC 11801 .
All test methods apply for two and four pair connectors.
All figures show schemes for four pair cabling and are also suitable for two pair cabling.
