BS EN 60534-2-5:2003

This standard BS EN 60534-2-5:2003 Industrial-process control valves. Flow capacity is classified in these ICS categories:

• 25.040.40 Industrial process measurement and control
• 23.060.40 Pressure regulators

This part of IEC 60534 includes equations for predicting the flow of compressible and incompressible fluids through multistage control valves.

The equations for incompressible flow are based on standard hydrodynamic equations for Newtonian incompressible fluids. They are not intended for use when non-Newtonian fluids, fluid mixtures, slurries, or liquid-solid conveyance systems are encountered.

At very low ratios of pressure differential to absolute inlet pressure (Δp/p₁), compressible fluids behave similarly to incompressible fluids. Under such conditions, the sizing equations for compressible flow can be traced to the standard hydrodynamic equations for Newtonian incompressible fluids. However, increasing values of Δp/p₁ result in compressibility effects which require that the basic equations be modified by appropriate correction factors. The equations for compressible fluids are for use with gas or vapour and are not intended for use with multiphase streams such as gas-liquid, vapour-liquid or gas-solid mixtures.

This standard is applicable only to those designs of multistage multipath control valves and multistage single path control valves.
