BS EN 60570:2003+A2:2020 Electrical Supply Track Systems for Luminaires

Welcome to the comprehensive guide on the BS EN 60570:2003+A2:2020 standard, a pivotal document for anyone involved in the design, installation, and maintenance of electrical supply track systems for luminaires. This standard is an essential resource for ensuring safety, efficiency, and compliance in lighting systems.

Overview

The BS EN 60570:2003+A2:2020 standard provides detailed specifications and guidelines for electrical supply track systems used in luminaires. These systems are crucial for delivering power to lighting fixtures in a safe and efficient manner. The standard ensures that these systems meet the necessary safety and performance requirements, making it an indispensable tool for engineers, designers, and technicians in the lighting industry.

Key Features

• Standard Number: BS EN 60570:2003+A2:2020
• Pages: 34
• Released: 2020-04-02
• ISBN: 978 0 580 98771 7
• Status: Standard

Why This Standard is Important

Electrical supply track systems are integral to modern lighting solutions, providing flexibility and adaptability in various settings, from residential to commercial spaces. The BS EN 60570:2003+A2:2020 standard ensures that these systems are designed and installed to the highest safety and performance standards. By adhering to this standard, you can be confident that your lighting systems are reliable, efficient, and compliant with current regulations.

Comprehensive Coverage

This standard covers a wide range of topics related to electrical supply track systems, including:

• Design and construction requirements
• Safety and performance criteria
• Testing methods and procedures
• Installation guidelines
• Maintenance and inspection protocols

With 34 pages of detailed information, this standard provides a thorough understanding of the requirements and best practices for electrical supply track systems.

Who Should Use This Standard?

The BS EN 60570:2003+A2:2020 standard is designed for a wide range of professionals in the lighting and electrical industries, including:

• Electrical engineers
• Lighting designers
• Installation technicians
• Maintenance personnel
• Compliance officers

By utilizing this standard, these professionals can ensure that their work meets the highest standards of safety and quality.

Benefits of Compliance

Compliance with the BS EN 60570:2003+A2:2020 standard offers numerous benefits, including:

• Enhanced Safety: Ensures that electrical supply track systems are safe for use, reducing the risk of electrical hazards.
• Improved Performance: Guarantees that systems operate efficiently and effectively, providing optimal lighting solutions.
• Regulatory Compliance: Helps organizations meet legal and regulatory requirements, avoiding potential fines and penalties.
• Increased Reliability: Ensures that systems are durable and dependable, minimizing downtime and maintenance costs.

Conclusion

The BS EN 60570:2003+A2:2020 standard is an essential resource for anyone involved in the design, installation, and maintenance of electrical supply track systems for luminaires. By adhering to this standard, you can ensure that your lighting systems are safe, efficient, and compliant with the latest regulations. Whether you are an engineer, designer, or technician, this standard provides the guidance and information you need to excel in your field.

Invest in the BS EN 60570:2003+A2:2020 standard today and take the first step towards safer, more efficient lighting solutions.

BS EN 60570:2003+A2:2020

This standard BS EN 60570:2003+A2:2020 Electrical supply track systems for luminaires is classified in these ICS categories:

• 29.120.20 Connecting devices
• 29.140.40 Luminaires

This International Standard applies to the following track systems with two or more poles for the connection of luminaires to the electrical supply consisting of, either

• a system with a rated voltage not exceeding 440 V between poles (live conductors) with provision for earthing (class I) and a rated current not exceeding 16 A per conductor, or

• a SELV system without provision for protective earthing (class III) and a rated current not exceeding 25 A per conductor, or

• a combination of the two systems mentioned above (mixed supply system) for the connection of both mains voltage luminaires (class I or II) and SELV supplied luminaires (class III) simultaneously, but in different sector openings (mains or SELV).

The track systems may also provide for the mechanical support of the luminaires.

It applies to track systems designed for ordinary interior use for mounting on, or flush with, or suspended from walls and ceilings. These track systems are not intended for locations where special conditions prevail as in ships, vehicles and the like and in hazardous locations, for example, where explosions are liable to occur.

This document does not cover operational or performance compatibility between different track systems. Protection against unsafe compatibility between Class I and Class III circuit is covered by this document.

The track system can be provided with auxiliary circuits for the purpose of a control or audio signal other than supply.

Track systems can also be provided with conductors specifically identified for emergency lighting luminaires.

NOTE 1 At present, the following types of control systems are available on the market:

• control signal, with basic insulation to LV supply (e.g. digital addressable lighting interface, 1 V to 10 V DC signal);

• control signal, SELV/PELV insulated to LV supply (e.g. dmX);

• control signal, not insulated to LV supply (e.g. push button control/phase cut/step dim).

NOTE 2 Requirements for PELV are under consideration, pending modification in IEC 60598-1.
