BS EN 61169-47:2015
Radio-frequency connectors Sectional specification for radio-frequency coaxial connectors with clamp coupling, typically for use in 75 Ω cable networks (type F-Quick)
| Standard number: | BS EN 61169-47:2015 |
| Pages: | 28 |
| Released: | 2015-07-31 |
| ISBN: | 978 0 580 85908 3 |
| Status: | Standard |
BS EN 61169-47:2015
This standard BS EN 61169-47:2015 Radio-frequency connectors is classified in these ICS categories:
- 33.120.30 RF connectors
This part of IEC 61169 , which is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for RF coaxial connectors with clamp coupling, typically for use in 75 Ω cable networks (type F-Quick).
It describes the interface dimensions with gauging information, electrical and mechanical performance including the mandatory tests selected from IEC 61169‑1:2013 , applicable to all DS relating to type F-Quick connectors.
This specification indicates the recommended performance characteristics to be considered when writing a DS and covers test schedules and inspection requirements.
This interface is typically used for indoor connections, which are easily disconnected and reconnected. The typical application is for F-type coaxial receiver leads or F-type coaxial patch cables. The interface may also be known as a Push-on connector. It is preferred to use the fixed (screwed) connectors type F according to IEC 61169‑24:2009 .
