immediate downloadReleased: 2016-03-31
BS EN 6123:2016
Aerospace series. Fitting end, 24° internal cone, external thread, flareless type. Extra fine thread pitch. Inch series. Design standard
Format
Availability
Price and currency
English Secure PDF
Immediate download
180.00 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
18.00 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
54.00 EUR
English Hardcopy
In stock
180.00 EUR
| Standard number: | BS EN 6123:2016 |
| Pages: | 16 |
| Released: | 2016-03-31 |
| ISBN: | 978 0 580 90776 0 |
| Status: | Standard |
DESCRIPTION
BS EN 6123:2016
This standard BS EN 6123:2016 Aerospace series. Fitting end, 24° internal cone, external thread, flareless type. Extra fine thread pitch. Inch series. Design standard is classified in these ICS categories:
- 49.080 Aerospace fluid systems and components
This European Standard specifies the dimensions, tolerances and the required characteristics of a fitting end, 24° cone, external thread, flareless type, size -04 up to -20 for use in hydraulic and fluid systems at 5 080 psi, diameter 1/4 inch ≤ D ≤ 1 1/4 inch (6,35 mm ≤ D ≤ 31,75 mm) for aerospace applications.
This is a design standard.
This fitting end cannot be used for plug in union.
