BS EN 61967-2:2005 Integrated circuits. Measurement of electromagnetic emissions, 150 kHz to 1 GHz Measurement of radiated emissions. TEM cell and wideband TEM cell method

BS EN 61967-2:2005

Integrated circuits. Measurement of electromagnetic emissions, 150 kHz to 1 GHz Measurement of radiated emissions. TEM cell and wideband TEM cell method

Format
Availability
Price and currency
English Secure PDF
Immediate download
249.60 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
24.96 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
74.88 EUR
English Hardcopy
In stock
249.60 EUR
Standard number:BS EN 61967-2:2005
Pages:26
Released:2006-01-23
ISBN:0 580 47476 3
Status:Standard
DESCRIPTION

BS EN 61967-2:2005


This standard BS EN 61967-2:2005 Integrated circuits. Measurement of electromagnetic emissions, 150 kHz to 1 GHz is classified in these ICS categories:
  • 31.080.99 Other semiconductor devices
  • 29.240.99 Other equipment related to power transmission and distribution networks
  • 29.200 Rectifiers. Converters. Stabilized power supply
  • 33.100.10 Emission
  • 31.200 Integrated circuits. Microelectronics
This test procedure defines a method for measuring the electromagnetic radiation from an integrated circuit (IC). The IC being evaluated is mounted on an IC test printed circuit board (PCB) that is clamped to a mating port (referred to as a wall port) cut in the top or bottom of a transverse electromagnetic (TEM) or wideband gigahertz TEM (GTEM) cell. The test board is not inside the cell, as in the conventional usage, but becomes a part of the cell wall. This method is applicable to any TEM or GTEM cell modified to incorporate the wall port; however, the measured radio frequency (RF) voltage will be affected by many factors. The primary factor affecting the measured RF voltage is the septum to IC test board (cell wall) spacing. This procedure was developed using a 1 GHz TEM cell with a septum to floor spacing of 45 mm and a GTEM cell with average septum to floor spacing of 45 mm over the port area. Other cells may not produce identical spectral output but may be used for comparative measurements, subject to their frequency and sensitivity limitations. A conversion factor may allow comparisons between data measured on TEM or GTEM cells with different septum to floor spacing. The IC test board controls the geometry and orientation of the operating IC relative to the cell and eliminates any connecting leads within the cell (these are on the backside of the board, which is outside the cell). For the TEM cell, one of the 50 ports is terminated with a 50 load. The other 50 port for a TEM cell, or the single 50 port for a GTEM cell, is connected to the input of a spectrum analyser or receiver that measures the RF emissions emanating from the integrated circuit and impressed onto the septum of the cell.
