Semiconductor devices. Micro-electromechanical devices Forming limit measuring method of metallic film materials
Format
Availability
Price and currency
English Secure PDF
Immediate download
181.70 EUR
English Hardcopy
In stock
181.70 EUR
Standard number:
BS EN 62047-14:2012
Pages:
22
Released:
2012-05-31
ISBN:
978 0 580 72297 4
Status:
Standard
DESCRIPTION
BS EN 62047-14:2012
This standard BS EN 62047-14:2012 Semiconductor devices. Micro-electromechanical devices is classified in these ICS categories:
31.080.99 Other semiconductor devices
IEC 62047-14:2012 describes definitions and procedures for measuring the forming limit of metallic film materials with a thickness range from 0,5 ?m to 300 ?m. The metallic film materials described herein are typically used in electric components, MEMS and micro-devices. When metallic film materials used in MEMS (see 2.1.2 of IEC 62047-1:2005) are fabricated by a forming process such as imprinting, it is necessary to predict the material failure in order to increase the reliability of the components. Through this prediction, the effectiveness of manufacturing MEMS components by a forming process can also be improved, because the period of developing a product can be reduced and manufacturing costs can thus be decreased. This standard presents one of the prediction methods for material failure in imprinting process.
