immediate downloadReleased: 2015-01-31
BS EN 62744:2015 Representation of states of objects by graphical symbols

BS EN 62744:2015

Representation of states of objects by graphical symbols

Format
Availability
Price and currency
English Secure PDF
Immediate download
292.80 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
29.28 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
87.84 EUR
English Hardcopy
In stock
292.80 EUR
Standard number:BS EN 62744:2015
Pages:36
Released:2015-01-31
ISBN:978 0 580 76113 3
Status:Standard
DESCRIPTION

BS EN 62744:2015


This standard BS EN 62744:2015 Representation of states of objects by graphical symbols is classified in these ICS categories:
  • 01.080.20 Graphical symbols for use on specific equipment
IEC 62744:2014 provides generic rules for the representation of states of objects by graphical symbols standardized in IEC 60617, ISO 14617, IEC 60417, for example, and for future graphical symbols included in these standards. It also provides operational states of an object as examples that typically occur and which need to be represented by standardized graphical symbols and defines generic rules to be applied. It specifies which types of presentation facilities are recommended to present the different operational states to humans.
