BS EN IEC 63093-6:2018 Ferrite Cores: Essential Guidelines for Power Supply Applications

Introducing the BS EN IEC 63093-6:2018 standard, a comprehensive guide that sets the benchmark for the dimensions and surface irregularities of ETD-cores used in power supplies. This standard is an indispensable resource for engineers, manufacturers, and quality assurance professionals who are involved in the design, production, and application of ferrite cores in power supply systems.

Overview of the Standard

The BS EN IEC 63093-6:2018 standard provides detailed guidelines on the dimensions and permissible surface irregularities of ETD-cores, which are crucial components in power supply applications. Released on September 3, 2019, this standard ensures that the ferrite cores used in your power supply systems meet the highest quality and performance criteria.

Key Features:

• Standard Number: BS EN IEC 63093-6:2018
• Pages: 30
• ISBN: 978 0 580 98334 4
• Status: Standard

Why Choose BS EN IEC 63093-6:2018?

Ferrite cores are integral to the efficiency and reliability of power supplies. The BS EN IEC 63093-6:2018 standard provides a structured approach to ensuring that these components are manufactured to precise specifications, minimizing the risk of performance issues and enhancing the overall quality of the power supply systems.

Benefits of Compliance:

• Enhanced Performance: By adhering to the guidelines, manufacturers can ensure that their ferrite cores contribute to optimal power supply performance.
• Quality Assurance: The standard provides a clear framework for assessing the quality of ferrite cores, helping to maintain high standards in production.
• Cost Efficiency: Reducing surface irregularities and adhering to precise dimensions can lead to fewer defects and lower production costs.
• Global Recognition: As an internationally recognized standard, compliance with BS EN IEC 63093-6:2018 can enhance your product's credibility in the global market.

Detailed Insights into ETD-Cores

ETD-cores are a specific type of ferrite core used extensively in power supply applications due to their excellent magnetic properties and efficiency. The BS EN IEC 63093-6:2018 standard provides detailed guidelines on the dimensions and surface irregularities of these cores, ensuring they meet the rigorous demands of modern power supply systems.

Core Specifications:

The standard outlines the acceptable limits for surface irregularities, which can affect the core's magnetic properties and, consequently, the efficiency of the power supply. By following these guidelines, manufacturers can produce ETD-cores that deliver consistent performance and reliability.

Who Should Use This Standard?

The BS EN IEC 63093-6:2018 standard is essential for a wide range of professionals, including:

• Design Engineers: To ensure that their designs incorporate components that meet industry standards.
• Manufacturers: To maintain high production standards and reduce the risk of defects.
• Quality Assurance Teams: To verify that products meet the required specifications and performance criteria.
• Procurement Specialists: To source components that comply with international standards, ensuring quality and reliability.

Conclusion

In the fast-evolving world of power supply technology, staying ahead requires adherence to the highest standards of quality and performance. The BS EN IEC 63093-6:2018 standard is your guide to achieving excellence in the production and application of ferrite cores. By following these guidelines, you can ensure that your power supply systems are efficient, reliable, and ready to meet the demands of the future.

Invest in the BS EN IEC 63093-6:2018 standard today and take the first step towards superior power supply solutions.

BS EN IEC 63093-6:2018

This standard BS EN IEC 63093-6:2018 Ferrite cores. Guidelines on dimensions and the limits of surface irregularities is classified in these ICS categories:

• 29.100.10 Magnetic components

This part of IEC 63093 specifies the dimensions that are of importance for mechanical interchangeability for a preferred range of ETD-cores made of ferrite and the essential dimensions of coil formers to be used with them, as well the effective parameter values to be used in calculations involving them. It also gives guidelines on allowable limits of surface irregularities applicable to ETD-cores.

The specifications contained in this document are useful in negotiations between ferrite core manufacturers and users about surface irregularities.

The use of derived standards which give more detailed specifications of component parts while still permitting compliance with this document is discussed in Annex A.
