BS EN ISO 1179-2:2022 Connections for general use and fluid power. Ports and stud ends with ISO 228-1 threads with elastomeric or metal-to-metal sealing Heavy-duty (S series) and light-duty (L series) stud ends with elastomeric sealing (type E)

BS EN ISO 1179-2:2022

Connections for general use and fluid power. Ports and stud ends with ISO 228-1 threads with elastomeric or metal-to-metal sealing Heavy-duty (S series) and light-duty (L series) stud ends with elastomeric sealing (type E)

Format
Availability
Price and currency
English Secure PDF
Immediate download
180.00 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standard
for 1 hour
18.00 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standard
for 24 hours
54.00 EUR
English Hardcopy
In stock
180.00 EUR
Standard number:BS EN ISO 1179-2:2022
Pages:18
Released:2022-11-25
ISBN:978 0 539 12409 5
Status:Standard
BS EN ISO 1179-2:2022 - Connections for General Use and Fluid Power

BS EN ISO 1179-2:2022 - Connections for General Use and Fluid Power

Standard Number: BS EN ISO 1179-2:2022

Pages: 18

Released: 2022-11-25

ISBN: 978 0 539 12409 5

Status: Standard

Overview

The BS EN ISO 1179-2:2022 standard is an essential document for professionals working in the field of fluid power and general use connections. This standard provides comprehensive guidelines and specifications for ports and stud ends with ISO 228-1 threads, ensuring reliable and efficient sealing, whether elastomeric or metal-to-metal.

Key Features

  • Heavy-duty (S series) and light-duty (L series) stud ends: This standard covers both heavy-duty and light-duty stud ends, catering to a wide range of applications and ensuring versatility in use.
  • Elastomeric sealing (type E): The inclusion of elastomeric sealing ensures a secure and leak-proof connection, enhancing the reliability and performance of the system.
  • ISO 228-1 threads: The use of ISO 228-1 threads guarantees compatibility with a wide range of components, making this standard highly adaptable and user-friendly.

Benefits

Adopting the BS EN ISO 1179-2:2022 standard offers numerous benefits, including:

  • Enhanced Reliability: The detailed specifications and guidelines ensure that connections are secure and reliable, reducing the risk of leaks and system failures.
  • Improved Efficiency: By following this standard, professionals can achieve optimal performance and efficiency in their fluid power systems.
  • Cost Savings: The use of standardized components and connections can lead to significant cost savings in terms of maintenance and replacement parts.
  • Global Compatibility: The ISO 228-1 threads ensure that components are compatible with international standards, facilitating global trade and collaboration.

Applications

The BS EN ISO 1179-2:2022 standard is applicable in a wide range of industries and applications, including:

  • Hydraulic Systems: Ensuring secure and reliable connections in hydraulic systems, enhancing performance and safety.
  • Pneumatic Systems: Providing guidelines for connections in pneumatic systems, ensuring efficient and leak-free operation.
  • Industrial Machinery: Facilitating the use of standardized connections in various types of industrial machinery, improving compatibility and ease of maintenance.
  • Automotive Industry: Ensuring reliable connections in automotive fluid power systems, enhancing vehicle performance and safety.

Technical Specifications

The BS EN ISO 1179-2:2022 standard includes detailed technical specifications to ensure the highest level of performance and reliability. Key technical aspects covered in the standard include:

  • Thread Specifications: Detailed guidelines for ISO 228-1 threads, ensuring compatibility and ease of use.
  • Sealing Methods: Specifications for both elastomeric and metal-to-metal sealing, providing options for different applications and requirements.
  • Material Requirements: Guidelines for the materials used in ports and stud ends, ensuring durability and performance.
  • Testing Procedures: Detailed testing procedures to verify the performance and reliability of connections, ensuring compliance with the standard.

Why Choose BS EN ISO 1179-2:2022?

The BS EN ISO 1179-2:2022 standard is a trusted and reliable resource for professionals in the fluid power and general use connections industry. By adhering to this standard, you can ensure that your systems are built to the highest level of quality and performance. Key reasons to choose this standard include:

  • Comprehensive Guidelines: The standard provides detailed and comprehensive guidelines, covering all aspects of ports and stud ends with ISO 228-1 threads.
  • Industry Recognition: As an internationally recognized standard, BS EN ISO 1179-2:2022 is trusted by professionals and organizations worldwide.
  • Up-to-Date Information: Released on 2022-11-25, this standard includes the latest information and best practices, ensuring that you are working with the most current guidelines.
  • Enhanced Performance: By following the specifications and guidelines in this standard, you can achieve enhanced performance and reliability in your fluid power systems.

Conclusion

The BS EN ISO 1179-2:2022 standard is an invaluable resource for professionals working with fluid power and general use connections. With its comprehensive guidelines, detailed specifications, and focus on reliability and performance, this standard is essential for ensuring the highest level of quality in your systems. Whether you are working with hydraulic or pneumatic systems, industrial machinery, or automotive applications, the BS EN ISO 1179-2:2022 standard provides the information and guidance you need to achieve optimal results.

DESCRIPTION

BS EN ISO 1179-2:2022


This standard BS EN ISO 1179-2:2022 Connections for general use and fluid power. Ports and stud ends with ISO 228-1 threads with elastomeric or metal-to-metal sealing is classified in these ICS categories:
  • 23.100.40 Piping and couplings
This document specifies the dimensions, performance requirements and test procedures for heavy-duty (S series) and light-duty (L series) stud ends with threads, and the elastomeric sealing (type E) that is used with them as defined in ISO 228-1. Heavy-duty (S series) stud ends with type E sealing in accordance with this document can be used at working pressures up to 63 MPa (630 bar). Light-duty (L series) stud ends with type E sealing in accordance with this document can be used at working pressures up to 25 MPa (250 bar). The permissible working pressure depends upon size, materials, design, working conditions, application, etc. This document is applicable to connectors detailed in ISO 8434-1, ISO 8434-2 and ISO 8434-6. NOTE      The Introduction gives recommendations for ports and stud ends to be used for new designs in hydraulic and pneumatic fluid power applications.
