BS EN ISO 5211:2017 Industrial valves. Part-turn actuator attachments

BS EN ISO 5211:2017

Industrial valves. Part-turn actuator attachments

CURRENCY
292.8 EUR
Standard number:BS EN ISO 5211:2017
Pages:34
Released:2017-06-16
ISBN:978 0 580 80377 2
Status:Standard
DESCRIPTION

BS EN ISO 5211:2017


This standard BS EN ISO 5211:2017 Industrial valves. Part-turn actuator attachments is classified in these ICS categories:
  • 23.060.01 Valves in general

This document specifies requirements for the attachment of part-turn actuators, with or without gearboxes, to industrial valves.

The attachment of part-turn actuators to control valves in accordance with the requirements of this document is subject to an agreement between the supplier and the purchaser.

This document specifies:

  • flange dimensions necessary for the attachment of part-turn actuators to industrial valves [see Figures 1 a) and 1 c)] or to intermediate supports [see Figures 1 b) and 1 d)];

  • driving component dimensions of part-turn actuators necessary to attach them to the driven components;

  • reference values for torques for interfaces and for couplings having the dimensions specified in this document.

The attachment of the intermediate support to the valve is out of the scope of this document.

NOTE 1 In this document, the term “valve” may also be understood to include “valve with an intermediate support” [see Figure 1 b)].

NOTE 2 When a combination of a multi-turn actuator and separate part-turn gearbox is coupled to form a part-turn actuator, the multi-turn attachment to the gearbox is in accordance with ISO 5210:2017, Figures 1 c) and 1 d). A combination of a multi-turn actuator with integral part-turn gearbox supplied as a part-turn actuator is in accordance with Figures 1a) and 1b).

Figure 1 Interface between part-turn actuator and valve


a)   Direct interface b)   Intermediate
        support interface
c)   Direct interface
      (when combination
      of a multi-turn
      actuator and a
      gearbox)
d)   Intermediate support
        interface (when
        combination of a multi-
        turn actuator and a
        gearbox)

Key

1 part-turn actuator 5 gearbox
2 interface (see ISO 5211) 6 interface (see ISO 5210)
3 valve 7 multi-turn actuator
4 intermediate support
