immediate downloadReleased: 2018-02-20
BS EN ISO 6412-1:2018
Technical product documentation. Simplified representation of pipelines General rules and orthogonal representation
Format
Availability
Price and currency
English Secure PDF
Immediate download
191.18 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
19.12 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
57.35 EUR
English Hardcopy
In stock
191.18 EUR
| Standard number: | BS EN ISO 6412-1:2018 |
| Pages: | 20 |
| Released: | 2018-02-20 |
| ISBN: | 978 0 580 97860 9 |
| Status: | Standard |
DESCRIPTION
BS EN ISO 6412-1:2018
This standard BS EN ISO 6412-1:2018 Technical product documentation. Simplified representation of pipelines is classified in these ICS categories:
- 01.100.99 Other standards related to technical drawings
- 01.100.20 Mechanical engineering drawings
- 23.040.01 Pipeline components and pipelines in general
This document specifies rules and conventions for the execution of simplified drawings for the representation of all kinds of pipes and pipelines made of all sorts of materials (rigid and flexible).
It is used whenever it is necessary to represent pipes or pipelines in a simplified manner.
For the purposes of this document, the figures illustrate the text only and should not be considered as design examples.
NOTE This document can also be used for the representation of similar installations, such as ventilation or air-conditioning systems; in such cases, the term "duct", etc. is substituted for the term "pipe".
