immediate downloadReleased: 2018-10-30
BS EN ISO 6413:2018
Technical product documentation. Representation of splines and serrations
Format
Availability
Price and currency
English Secure PDF
Immediate download
180.00 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
18.00 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
54.00 EUR
English Hardcopy
In stock
180.00 EUR
| Standard number: | BS EN ISO 6413:2018 |
| Pages: | 20 |
| Released: | 2018-10-30 |
| ISBN: | 978 0 580 89572 2 |
| Status: | Standard |
DESCRIPTION
BS EN ISO 6413:2018
This standard BS EN ISO 6413:2018 Technical product documentation. Representation of splines and serrations is classified in these ICS categories:
- 21.120.30 Keys and keyways, splines
- 01.100.20 Mechanical engineering drawings
This document specifies the rules and graphical symbols for the representations of splines and serrations in technical product documentation.
Two methods of representation are specified:
complete representation;
simplified representation.
The rules and graphical symbols specified in this document are applicable to detail drawings of parts (shafts and hubs) and to assembly drawings of joints.
NOTE For uniformity, all the figures in this document have been drawn in the first-angle orthographic projection. A third-angle orthographic projection could equally have been used without prejudice to principles established.
