immediate downloadReleased: 1995-10-15
BS EN ISO 9222-1:1995
Technical drawings. Seals for dynamic application General simplified representation
Format
Availability
Price and currency
English Secure PDF
Immediate download
151.20 EUR
You can read the standard for 1 hour. More information in the category: E-reading
Reading the standardfor 1 hour
15.12 EUR
You can read the standard for 24 hours. More information in the category: E-reading
Reading the standardfor 24 hours
45.36 EUR
English Hardcopy
In stock
151.20 EUR
| Standard number: | BS EN ISO 9222-1:1995 |
| Pages: | 10 |
| Released: | 1995-10-15 |
| ISBN: | 0 580 23763 X |
| Status: | Standard |
DESCRIPTION
BS EN ISO 9222-1:1995
This standard BS EN ISO 9222-1:1995 Technical drawings. Seals for dynamic application is classified in these ICS categories:
- 01.100.20 Mechanical engineering drawings
- 21.140 Seals, glands
This part of ISO 9222 specifies the general simplified representation for seals.
This representation should be used when it is not necessary to show the exact shape and details of the seals, for example in assembly drawings.
